About

The Live Broadcast Bundle will make it possible to plan live video streams to various channels like Twitch, YouTube Live, Facebook Live (referred to as Output or Channels).

As "Input" we support files, URL's or existing RTMP streams.

For more info you can view the latest recorded presentation below, check the demo project at https://github.com/Martin1982/live-broadcast-demo or read on;

Prerequisites

The Broadcaster needs a few commands;

ffmpeg 3.x or higher

On Linux:

ps
kill

On Mac:

ps
grep
kill

On Windows:

tasklist
taskkill

To test these prerequisites the Symfony command livebroadcaster:test:shell can be used after the installation described below.

Basic installation

This bundle will be made available on Packagist. You can then install it using Composer:

$ composer require martin1982/live-broadcast-bundle

Next, for Symfony < 4 enable the bundle in the kernel:

<?php
// app/AppKernel.php

public function registerBundles()
{
    $bundles = array(
        // ...
        new Martin1982\LiveBroadcastBundle\LiveBroadcastBundle(),
    );
}

Use Doctrine to update your database schema with the broadcasting entities, when upgrading it is recommended to use migrations.

To start the broadcast scheduler you can run the following command:

$ php app/console livebroadcaster:broadcast

To make broadcast planning available through an admin interface we've added support for the Sonata Admin bundle.

FFMpeg log directory

To view the output of FFMpeg you need to configure a log directory in your app/config/config.yml.

 live_broadcast:
    ffmpeg:
        log_directory: '%kernel.logs_dir%'

Event loop

You can use this configuration to set the event loop timer:

live_broadcast:
    eventloop:
        timer: 5

Thumbnailer setup

Setup the following config for thumbnails:

live_broadcast:
    thumbnail:
        upload_directory: '%kernel.root_dir%/../web/uploads/thumbnails'
        web_path: '/uploads/thumbnails'

Enabling Facebook Live

Create a Facebook app on https://developers.facebook.com with the following permissions:

user_videos
user_events
user_managed_groups
manage_pages
publish_actions
Live-Video API

Edit your app/config/config.yml with the following configuration:

live_broadcast:
    facebook:
        application_id: YourFacebookAppId
        application_secret: YourFacebookAppSecret

When using Sonata Admin; add the Sonata block to your blocks config:

sonata_block:
    blocks:
    sonata.block.service.facebookauth:
        contexts:   [admin]

Enabling YouTube Live

Setup oAuth Credentials for your server. In case you're using the Sonata Admin from this bundle the redirect URI's path is <your domain>/admin/channel/youtube/oauthprovider

Add the YouTube API info to your config.yml:

live_broadcast:
    youtube:
        client_id: YourGoogleOauthClientId
        client_secret: YourGoogleOauthClientSecret
        redirect_route: admin_martin1982_livebroadcast_channel_abstractchannel_youtubeoauth

When using Sonata Admin; add the Sonata block to your blocks config:

sonata_block:
    blocks:
    sonata.block.service.youtubeauth:
        contexts:   [admin]

Add these lines to your parameters.yml (used for generating a thumbnail URL)

parameters:
    router.request_context.host: broadcast.com
    router.request_context.scheme: https

Add new output platforms

Create a new Channel Entity in Entity/Channel that extends the AbstractChannel (e.g. ChannelNew)

Create a new StreamOutput service in Service/StreamOutput that implements the OutputInterface (e.g. OutputNew)

Configure the service with the output tag in Resources/config/services.yml

live.broadcast.output.new:
    class: Martin1982\LiveBroadcastBundle\Service\StreamOutput\OutputNew
    tags:
        - { name: live.broadcast.output, platform: 'New' }

To add support for Sonata admin; add a new form for the Channel in Admin/ChannelAdmin.php

protected function configureFormFields(FormMapper $formMapper)
{
    if ($subject instanceof ChannelNew) {
        $formMapper->add('...', 'text', array('label' => '...'));
    }
}

Next add the sub class for the channelAdmin in Resources/config/admin.yml for

sonata.admin.channel
    calls:
        - [setConfiguredSubclasses, [ { "Name": Martin1982\LiveBroadcastBundle\Entity\Channel\ChannelNew } ] ]
