Transform any Laravel model into a drag-and-drop Kanban board in minutes.

Latest Version Total Downloads PHP 8.3+ Filament 4 Tests

Flowforge Kanban Board

Why Flowforge?

Works with existing models - No new tables or migrations required
🚀 2-minute setup - From installation to working board
🎯 Filament-native - Integrates seamlessly with your admin panel

Note: For Filament v3 compatibility, use version 1.x of this package.

⚠️ Beta Warning: This is a beta version (2.x) and may contain breaking changes.

Quick Start

Install and create your first Kanban board:

composer require relaticle/flowforge
php artisan flowforge:make-board TaskBoard --model=Task

That's it! Add the generated page to your Filament panel and you have a working Kanban board.

📋 Show complete example
<?php

namespace App\Filament\Pages;

use App\Models\Task;
use Illuminate\Database\Eloquent\Builder;
use Relaticle\Flowforge\Board;
use Relaticle\Flowforge\BoardPage;
use Relaticle\Flowforge\Column;

class TaskBoardPage extends BoardPage
{
    protected static ?string $navigationIcon = 'heroicon-o-view-columns';

    public function getEloquentQuery(): Builder
    {
        return Task::query();
    }

    public function board(Board $board): Board
    {
        return $board
            ->query($this->getEloquentQuery())
            ->recordTitleAttribute('title')
            ->columnIdentifier('status')
            ->reorderBy('order_column')
            ->columns([
                Column::make('todo')->label('To Do')->color('gray'),
                Column::make('in_progress')->label('In Progress')->color('blue'),
                Column::make('completed')->label('Completed')->color('green'),
            ]);
    }
}

Requirements

  • PHP: 8.3+
  • Laravel: 11+
  • Filament: 4.x

Features

Feature Description
🔄 Model Agnostic Works with any Eloquent model
🏗️ No New Tables Uses your existing database structure
🖱️ Drag & Drop Intuitive card movement between columns
Minimal Setup 2 methods = working board
🎨 Customizable Colors, properties, actions
📱 Responsive Works on all screen sizes
🔍 Built-in Search Find cards instantly

Installation & Setup

1. Install the Package

composer require relaticle/flowforge

2. Prepare Your Model

Your model needs these fields:

  • Title field (e.g., title, name)
  • Status field (e.g., status, state)
  • Order field (e.g., order_column) - for drag & drop

Example migration:

Schema::create('tasks', function (Blueprint $table) {
    $table->id();
    $table->string('title');
    $table->string('status')->default('todo');
    $table->integer('order_column')->nullable();
    $table->timestamps();
});

3. Generate Board Page

php artisan flowforge:make-board TaskBoard --model=Task

4. Register with Filament

// app/Providers/Filament/AdminPanelProvider.php
->pages([
    App\Filament\Pages\TaskBoardPage::class,
])

Done! Visit your Filament panel to see your new Kanban board.

Configuration Examples

Basic Read-Only Board

Perfect for dashboards and overview pages:

public function board(Board $board): Board
{
    return $board
        ->query($this->getEloquentQuery())
        ->recordTitleAttribute('title')
        ->columnIdentifier('status')
        ->columns([
            Column::make('backlog')->label('Backlog'),
            Column::make('active')->label('Active'),
            Column::make('done')->label('Done')->color('green'),
        ]);
}

Interactive Board with Actions

Add create and edit capabilities:

use Filament\Actions\CreateAction;
use Filament\Actions\EditAction;
use Filament\Actions\DeleteAction;
use Filament\Forms\Components\TextInput;
use Filament\Forms\Components\Select;

public function board(Board $board): Board
{
    return $board
        ->query($this->getEloquentQuery())
        ->recordTitleAttribute('title')
        ->columnIdentifier('status')
        ->reorderBy('order_column')
        ->columns([
            Column::make('todo')->label('To Do')->color('gray'),
            Column::make('in_progress')->label('In Progress')->color('blue'),
            Column::make('completed')->label('Completed')->color('green'),
        ])
        ->columnActions([
            CreateAction::make('create')
                ->label('Add Task')
                ->icon('heroicon-o-plus')
                ->model(Task::class)
                ->form([
                    TextInput::make('title')->required(),
                    Select::make('priority')
                        ->options(['low' => 'Low', 'medium' => 'Medium', 'high' => 'High'])
                        ->default('medium'),
                ])
                ->mutateFormDataUsing(function (array $data, string $columnId): array {
                    $data['status'] = $columnId;
                    return $data;
                }),
        ])
        ->cardActions([
            EditAction::make('edit')->model(Task::class),
            DeleteAction::make('delete')->model(Task::class),
        ])
        ->cardAction('edit'); // Make cards clickable
}

Advanced Board with Schema

Use Filament's Schema system for rich card content:

use Filament\Infolists\Components\TextEntry;
use Filament\Schemas\Schema;

public function board(Board $board): Board
{
    return $board
        ->query($this->getEloquentQuery())
        ->recordTitleAttribute('title')
        ->columnIdentifier('status')
        ->cardSchema(fn (Schema $schema) => $schema
            ->components([
                TextEntry::make('priority')
                    ->badge()
                    ->color(fn ($state) => match ($state) {
                        'high' => 'danger',
                        'medium' => 'warning',
                        'low' => 'success',
                        default => 'gray',
                    }),
                TextEntry::make('due_date')
                    ->date()
                    ->icon('heroicon-o-calendar'),
                TextEntry::make('assignee.name')
                    ->icon('heroicon-o-user')
                    ->placeholder('Unassigned'),
            ])
        )
        ->columns([...]);
}

API Reference

Board Configuration Methods

Method Description Required
query(Builder|Closure) Set the data source
recordTitleAttribute(string) Field used for card titles
columnIdentifier(string) Field that determines column placement
columns(array) Define board columns
reorderBy(string, string) Enable drag & drop with field and direction
cardSchema(Closure) Configure card content with Filament Schema
cardActions(array) Actions for individual cards
columnActions(array) Actions for column headers
cardAction(string) Default action when cards are clicked
searchable(array) Enable search across specified fields

Livewire Methods (Available in your BoardPage)

Method Description Usage
updateRecordsOrderAndColumn(string, array) Handle drag & drop updates Automatic
loadMoreItems(string, ?int) Load more cards for pagination Automatic
getBoardRecord(int|string) Get single record by ID Manual
getBoardColumnRecords(string) Get all records for a column Manual
getBoardColumnRecordCount(string) Count records in a column Manual

Available Colors

gray, red, orange, yellow, green, blue, indigo, purple, pink

Troubleshooting

🔧 Cards not draggable

Cause: Missing order column or reorderBy configuration Solution:

  1. Add integer column to your migration: $table->integer('order_column')->nullable();
  2. Add ->reorderBy('order_column') to your board configuration
  3. Ensure your model's $fillable includes the order column

📭 Empty board showing

Cause: Query returns no results or status field mismatch Debug steps:

  1. Check query: dd($this->getEloquentQuery()->get());
  2. Verify status values match column names exactly
  3. Check database field type (string vs enum)

❌ Actions not working

Cause: Missing Filament traits or action configuration Solution:

  1. Ensure your BoardPage implements HasActions, HasForms
  2. Use these traits in your class:
use InteractsWithActions;
use InteractsWithForms;
use InteractsWithBoard;
  1. Configure actions properly with ->model(YourModel::class)

🔄 Drag & drop updates not saving

Cause: Missing primary key handling or invalid field names Solution:

  1. Ensure your model uses standard primary key or override getKeyName()
  2. Check status field accepts the column identifier values
  3. Verify order column exists and is fillable

💥 "No default Filament panel" error

Cause: Missing panel configuration in tests/development Solution: Add to your panel provider:

Panel::make()->default()->id('admin')

🎨 Styling not loading

Cause: Assets not built or registered Solution:

  1. Run npm run build to compile assets
  2. Ensure Filament can load the assets with proper permissions

Real-World Examples

Complete Task Management Board

<?php

namespace App\Filament\Pages;

use App\Models\Task;
use Filament\Actions\CreateAction;
use Filament\Actions\EditAction;
use Filament\Actions\DeleteAction;
use Filament\Forms\Components\Select;
use Filament\Forms\Components\TextInput;
use Filament\Forms\Components\DatePicker;
use Filament\Infolists\Components\TextEntry;
use Filament\Schemas\Schema;
use Illuminate\Database\Eloquent\Builder;
use Relaticle\Flowforge\Board;
use Relaticle\Flowforge\BoardPage;
use Relaticle\Flowforge\Column;

class TaskBoardPage extends BoardPage
{
    protected static ?string $navigationIcon = 'heroicon-o-view-columns';
    protected static ?string $navigationLabel = 'Task Board';

    public function getEloquentQuery(): Builder
    {
        return Task::query()->with('assignee');
    }

    public function board(Board $board): Board
    {
        return $board
            ->query($this->getEloquentQuery())
            ->recordTitleAttribute('title')
            ->columnIdentifier('status')
            ->reorderBy('order_column', 'desc')
            ->searchable(['title', 'description', 'assignee.name'])
            ->columns([
                Column::make('todo')->label('📋 To Do')->color('gray'),
                Column::make('in_progress')->label('🔄 In Progress')->color('blue'),
                Column::make('review')->label('👁️ Review')->color('purple'),
                Column::make('completed')->label('✅ Completed')->color('green'),
            ])
            ->cardSchema(fn (Schema $schema) => $schema
                ->components([
                    TextEntry::make('priority')
                        ->badge()
                        ->color(fn ($state) => match ($state) {
                            'high' => 'danger',
                            'medium' => 'warning',
                            'low' => 'success',
                            default => 'gray',
                        }),
                    TextEntry::make('due_date')
                        ->date()
                        ->icon('heroicon-o-calendar')
                        ->color('orange'),
                    TextEntry::make('assignee.name')
                        ->icon('heroicon-o-user')
                        ->placeholder('Unassigned'),
                ])
            )
            ->columnActions([
                CreateAction::make('create')
                    ->label('Add Task')
                    ->icon('heroicon-o-plus')
                    ->model(Task::class)
                    ->form([
                        TextInput::make('title')->required(),
                        Select::make('priority')
                            ->options(['low' => 'Low', 'medium' => 'Medium', 'high' => 'High'])
                            ->default('medium'),
                        DatePicker::make('due_date'),
                    ])
                    ->mutateFormDataUsing(function (array $data, string $columnId): array {
                        $data['status'] = $columnId;
                        return $data;
                    }),
            ])
            ->cardActions([
                EditAction::make('edit')
                    ->model(Task::class)
                    ->form([
                        TextInput::make('title')->required(),
                        Select::make('status')
                            ->options([
                                'todo' => 'To Do',
                                'in_progress' => 'In Progress',
                                'review' => 'Review',
                                'completed' => 'Completed',
                            ]),
                        Select::make('priority')
                            ->options(['low' => 'Low', 'medium' => 'Medium', 'high' => 'High']),
                        DatePicker::make('due_date'),
                    ]),
                DeleteAction::make('delete')
                    ->model(Task::class)
                    ->requiresConfirmation(),
            ])
            ->cardAction('edit'); // Make cards clickable to edit
    }
}

Required Database Schema

CREATE TABLE tasks (
    id BIGINT UNSIGNED AUTO_INCREMENT PRIMARY KEY,
    title VARCHAR(255) NOT NULL,
    status VARCHAR(255) DEFAULT 'todo',
    order_column INT NULL,  -- Required for drag & drop
    priority VARCHAR(255) DEFAULT 'medium',
    due_date DATE NULL,
    assignee_id BIGINT UNSIGNED NULL,
    created_at TIMESTAMP NULL,
    updated_at TIMESTAMP NULL
);

Testing Your Board

// tests/Feature/TaskBoardTest.php
use Livewire\Livewire;

test('task board renders successfully', function () {
    Task::create(['title' => 'Test Task', 'status' => 'todo']);

    Livewire::test(TaskBoardPage::class)
        ->assertSuccessful()
        ->assertSee('Test Task')
        ->assertSee('To Do');
});

test('can move tasks between columns', function () {
    $task = Task::create(['title' => 'Test Task', 'status' => 'todo']);

    Livewire::test(TaskBoardPage::class)
        ->call('updateRecordsOrderAndColumn', 'completed', [$task->getKey()])
        ->assertSuccessful();

    expect($task->fresh()->status)->toBe('completed');
});

Need Help?

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.

License

MIT License. See LICENSE.md for details.

Built with ❤️ for the Laravel community
