README

LiveCharts

Reactive chart abstraction for Laravel — pure PHP API, multi-engine rendering, Livewire delivery.

LiveCharts unifies ApexCharts and Chart.js behind a single fluent PHP API. Define charts in PHP, render them with one Livewire component, and update them reactively from your application state — no JavaScript boilerplate, no engine-specific configuration leaking into your views.

Features

Fluent + class-based builders — LiveCharts::line()->labels(...)->dataset(...) or class extends Chart
18 chart types — line, bar, area, pie, donut, radar, scatter, bubble, heatmap, range bar, radial bar, polar area, box plot, treemap, candlestick, matrix, sankey, plus a generic factory
Multi-engine — ApexCharts and Chart.js out of the box, with LiveCharts::registerEngine() for custom adapters
Livewire-native rendering — single <livewire:livecharts :chart="$chart" /> component handles mount, hydration, and re-render
Reactive updates — bind chart data to Livewire properties; the component re-renders when state changes
Polling — Chart::poll(5000) + wire:poll="refresh" integration with a livecharts:refreshed event for userland data hydration
Interaction events — onDataPointClick, onZoom, onSelection, onScroll map directly to Livewire events
Broadcasting — push chart updates over Laravel Echo channels with broadcastOn() / broadcastAs()
Theme-aware color tokens — 289-case TwColor enum (all Tailwind v4 families + 4 extensions × 11 shades) with dark:/light: named-arg API: ->titleColor(dark: TwColor::Amber300, light: TwColor::Amber600). Charts re-color live on dark-mode toggle — no Livewire roundtrip
Palette presets — ->palette(TwPalette::Vibrant) auto-fills dataset colors from theme-aware preset schemes
Typography — ->titleFont(size: 18, weight: 'bold', family: 'Inter') for title, legend, and tooltip
Theme detection — auto, light, or dark modes; JS observer watches <html class="dark"> (or prefers-color-scheme) and re-colors charts live
Local-first assets with CDN fallback — engine bundles (apexcharts.js, chartjs.js) and Chart.js plugin bundles (treemap/matrix/sankey/financial/luxon/adapter-luxon) ship pre-built in resources/dist; switch between local, cdn, or both via config
Vite build pipeline — lib-mode IIFE outputs for livecharts.js + every engine and plugin shim, verified in CI
Stub publishing — livecharts:install can publish chart class stubs to stubs/livecharts for project-level customization
Browser preview — php artisan livecharts:preview launches a gallery of every chart type in your default browser
i18n — ships with en, pt_BR, and es translations
Type-safe — PHPStan level 8, PHP 8.2+, strict types throughout

Quick Start

composer require matheusmarnt/livecharts
php artisan livecharts:install

This will:

Publish config/livecharts.php
Copy the LiveCharts JS runtime + engine bundles to public/vendor/livecharts/js (local-first delivery with CDN fallback by default — LIVECHARTS_ASSETS_MODE=both)
Optionally publish chart class stubs to stubs/livecharts

Note: The default asset mode is both (local first, CDN fallback). The files in public/vendor/livecharts/js/ must exist for this to work. If you skip the install step or need to restore the assets after deployment, run:
php artisan vendor:publish --tag=livecharts-assets --force
If you prefer no local files at all, set LIVECHARTS_ASSETS_MODE=cdn in .env — no publish step needed.

Then build a chart and render it:

use Matheusmarnt\LiveCharts\Facades\LiveCharts;

$chart = LiveCharts::line()
    ->title('Monthly Revenue')
    ->labels(['Jan', 'Feb', 'Mar'])
    ->dataset('2026', [100, 200, 150])
    ->colors(['#3B82F6']);

<livewire:livecharts :chart="$chart" />

Place the asset directive once in your layout, before @livewireScripts and before the closing </body> tag (or in the <head> when using a Blade layout with @extends/@section):

{{-- must come BEFORE @livewireScripts — livecharts.js registers Alpine components before Alpine starts --}}
@liveChartsScripts
@livewireScripts

Building Charts

Fluent builder

Every method returns $this, so chains read top-down:

LiveCharts::bar()
    ->title('Sales by Region')
    ->subtitle('Q1 2026')
    ->labels(['North', 'South', 'East', 'West'])
    ->dataset('Sales', [400, 300, 600, 250])
    ->colors(['#10B981'])
    ->stacked()
    ->height(420)
    ->theme('auto');

Available factories: line, bar, area, pie, donut, radar, scatter, bubble, heatmap, rangeBar, radialBar, polarArea, boxPlot, treemap, candlestick, matrix, sankey, plus make() for the generic factory.

Class-based charts

Generate a dedicated class for reusable charts:

php artisan make:chart RevenueChart --type=bar

namespace App\Charts;

use Matheusmarnt\LiveCharts\Charts\Chart;
use Matheusmarnt\LiveCharts\Charts\Dataset;

class RevenueChart extends Chart
{
    protected string $type = 'bar';

    public function __construct()
    {
        parent::__construct();

        $this
            ->title('Revenue')
            ->labels(['Jan', 'Feb', 'Mar'])
            ->datasets([
                Dataset::make('2026')->data([400, 300, 600])->color('#10B981'),
            ]);
    }
}

<livewire:livecharts :chart="new App\Charts\RevenueChart" />

Stubs: running livecharts:install and accepting the stubs prompt publishes the generator stub to stubs/livecharts/chart.stub. Edit that file to customize the boilerplate emitted by make:chart.

Reactive Charts

Polling

$chart->poll(5000); // refresh every 5 seconds

The Livewire component subscribes via wire:poll="refresh" and dispatches a browser event on every tick:

window.addEventListener('livecharts:refreshed', (e) => {
    // e.detail.id — chart DOM id
})

Hydrate fresh data inside refresh() on a parent Livewire component, or react to the event on the client.

Click and zoom events

$chart
    ->onDataPointClick('chart-clicked')
    ->onZoom('chart-zoomed')
    ->onSelection('chart-selected');

In the parent component:

use Livewire\Attributes\On;

#[On('chart-clicked')]
public function handle(array $data): void
{
    // $data: ['seriesIndex' => 0, 'dataPointIndex' => 2, 'value' => 150, 'label' => 'Mar']
}

Broadcasting

$chart->broadcastOn('private-charts.'.$user->id)->broadcastAs('chart.updated');

Subscribe via Laravel Echo and the chart re-renders when the channel fires.

Multi-Engine

The default engine is apexcharts. Override globally in config/livecharts.php or per chart:

LiveCharts::line()->engine('chartjs')->labels(...)->dataset(...);

use App\LiveCharts\Engines\HighchartsAdapter;
use Matheusmarnt\LiveCharts\Facades\LiveCharts;

LiveCharts::registerEngine('highcharts', HighchartsAdapter::class);

Implement Matheusmarnt\LiveCharts\Contracts\EngineAdapter and the engine becomes selectable from any chart.

Commands

Command	Description
`livecharts:install`	Publish config, copy the JS runtime + engine bundles, optionally publish chart stubs
`make:chart {name} {--type=} {--engine=}`	Generate a new chart class under `app/Charts`; `--type`/`--engine` derived from `Chart::TYPES` and `EngineFactory::names()`
`livecharts:preview {--no-open}`	Open the gallery of every chart type at `/livecharts/preview` in your default browser; `--no-open` only prints the URL

Documentation

Installation guide — step-by-step setup, asset modes, engine selection, customization

Testing

composer test

Runs the Pest suite (288 tests) against the package's testbench harness — including 17 Pest arch rules, payload + adapter routing for every chart type, Livewire color-roundtrip tests (Bugs 1 & 5), ApexCharts themed-color path tests, script-stack idempotency tests, and integration tests for UC-01 dashboard, UC-02 drill-down, UC-03 polling, and UC-04 multi-tenant flows. CI matrix: PHP 8.2-8.5 × Laravel 11/12/13 × Livewire 3/4 × prefer-lowest/stable × Ubuntu/Windows, with a --min=90 coverage gate and PHPStan level 8 enforcement.

Changelog

See CHANGELOG for release history.

Contributing

See CONTRIBUTING for details.

Security

If you discover a security vulnerability, please email matheusmarnt@gmail.com instead of opening a public issue.

Credits

License

MIT — see LICENSE.
