README

Laravel Satim

Laravel package for integrating SATIM payment gateway with Laravel applications.

Installation

You can install the package via Composer:

composer require gts-meghni/laravel-satim

The package ships the audit trail migration, so run:

php artisan migrate

You may publish all of the package's resources at once:

php artisan vendor:publish --tag="satim"

The migration is not part of that tag, since the package already runs it. Publish it only to own the schema. Or, you may publish each resource individually:

Publishing the Configuration File

php artisan vendor:publish --tag="satim-config"

Publishing the Translations

php artisan vendor:publish --tag="satim-lang"

Publishing the Public Assets

php artisan vendor:publish --tag="satim-assets"

Configuration

Add your SATIM credentials to .env:

SATIM_BASE_URL=https://test2.satim.dz/payment/rest
SATIM_USER=your-merchant-user
SATIM_PASSWORD=your-merchant-password
SATIM_TERMINAL_ID=E0123456789
SATIM_RETURN_URL=https://example.test/satim/return
SATIM_FAIL_URL=https://example.test/satim/fail

Important

SATIM_BASE_URL has no default and must use HTTPS. The production host is not test2.satim.dz; obtain it from SATIM and set it explicitly per environment. Give it the REST root, without a trailing slash and without the endpoint segment.

SATIM requires both redirect URLs on every order, and both must be absolute URLs the gateway can reach. They are configured here and only here: register() sends the configured values and takes no URL arguments, so the gateway can only ever redirect a customer to an address this environment declared. A missing or relative URL raises SatimConfigurationException.

Optional: SATIM_CURRENCY (default 012, DZD) and SATIM_LANGUAGE (default FR, one of AR, FR, EN).

Verify the configuration as part of every deploy:

php artisan satim:check

It prints the resolved settings with the password masked and exits non-zero when a value is missing or invalid, so a bad release fails before a customer reaches checkout. The same validation runs at request time, raising SatimConfigurationException and naming the offending key rather than letting SATIM reject a half-empty request.

Usage

Registering an Order

use GtsMeghni\Satim\Facades\Satim;

$result = Satim::register(
    orderNumber: 'K9m2X7qL4P',                     // exactly 10 alphanumeric characters, unique
    amount: 5966.56,                               // in DZD; converted to centimes for SATIM
    description: 'Order K9m2X7qL4P',               // optional
);

if ($result->successful()) {
    // Persist $result->orderId, then hand $result->formUrl to the client, which sends the
    // customer to SATIM's payment page.
    return response()->json([
        'order_id' => $result->orderId,
        'form_url' => $result->formUrl,
    ]);
}

// SATIM rejected the registration; $result->errorCode explains why.
report(new RuntimeException("SATIM register failed: {$result->errorCode}"));

register() returns a RegisterResult and does not throw when SATIM rejects the order: a duplicate order number or a blocked merchant is a normal outcome you should record. It throws only for problems on your side or the wire:

Exception	Cause
`SatimValidationException`	An argument violates a documented SATIM constraint, caught before any HTTP call
`SatimConfigurationException`	A required config value is missing or invalid
`SatimConnectionException`	The gateway was unreachable, returned an error status, or answered with something other than a JSON object

RegisterResult exposes successful(), failed(), orderId, formUrl, errorCode, errorMessage, plus rawRequest and rawResponse for the audit trail. Credentials are redacted from rawRequest, so it is safe to persist.

Confirming the Payment

When SATIM sends the customer back, confirm the outcome. Do this on both the return and the fail URL: never trust the redirect alone, and SATIM cancels orders that are not confirmed.

$result = Satim::acknowledge($attempt->gateway_order_id);

if ($result->paid()) {
    // $result->message is ready to store, $result->amount is in dinars.
}

Whether the customer paid is decided by three fields read together (respCode 00, errorCode 0 and orderStatus 2), never by one alone. paid() applies that rule for you.


Outcome	`paid()`, `rejected()`, `message`
SATIM's own wording	`respCodeDesc`, `actionCodeDescription`, `errorMessage`
Codes	`respCode`, `errorCode`, `orderStatus`, `actionCode`
Payment	`orderId`, `orderNumber`, `amount` (dinars), `amountInCentimes`, `maskedCard`, `cardholderName`, `expiration`, `approvalCode`, `currency`, `ip`
For your records	`rawRequest` (credentials redacted), `rawResponse`

message is the text to persist, following the mapping in SATIM's integration guide. It is SATIM's own description in every case but one: when an authorisation is reversed (orderStatus 3) SATIM reports no error of its own, so fixed wording is used instead. SATIM's original text is still available in respCodeDesc and actionCodeDescription, so you can show the customer what the gateway actually said.

That fixed wording ships in the package's language files in French, English and Arabic, and follows the language you pass to acknowledge(), not the application locale, so it matches what the customer saw on the payment page. Publish satim-lang to change it.

Noticing Refunds and Cancellations

Refunds can be issued from your application (see below) or by staff inside SATIM's back office. Cancellations are back-office only. Either way, the order status is how you find out:

$result->refunded();     // refunded in the SATIM back office
$result->cancelled();    // authorisation reversed
$result->status;          // the named status, e.g. SatimOrderStatus::Refunded

status is a SatimOrderStatus covering the values SATIM's merchant portal documents, with isPaid(), isRefunded(), isCancelled(), and isReturned() for either of the last two. When SATIM sends a status outside that list, status is null and the raw number stays available on orderStatus.

Note

SATIM documents no endpoint for re-reading an order's state on demand, so there is nothing to poll: a refund or cancellation made in the back office shows up the next time you confirm the order. Ask SATIM for an order status endpoint if you need to check independently.

Issuing a Refund

refund.do returns money already deposited for an order. Your SATIM user needs the refund permission, and SATIM refuses a refund on an order that was never charged.

$result = Satim::refund($attempt->gateway_order_id, 200);   // 200 DZD

if ($result->successful()) {
    // $result->amountInCentimes is what SATIM was sent, $result->amount the same in dinars.
}

Several partial refunds against one order are allowed, as long as they do not add up to more than was deposited. Success here is errorCode 0 (unlike register, there is no identifier to look for), and a response the package cannot read counts as a failure rather than a success. A refused refund is reported through the result, not thrown: check successful() and keep both payloads.

RefundResult carries orderId, amountInCentimes, amount, errorCode, errorMessage, rawRequest (credentials redacted), and rawResponse.

Receipts

SATIM requires a receipt after a completed payment, offering print, PDF download, and email as PDF. The package supplies the contents; the page, the PDF, and the email are yours, so you can brand them freely.

$receipt = Satim::receipt($result);

SATIM requires its logo beside the hotline message and never on its own. Both the SATIM logo and the CIB/EDAHABIA logo ship with the package; publish them once and they are served from your app:

php artisan vendor:publish --tag="satim-assets"

Asset	Path after publishing	Used for
`satim.png`	`/vendor/satim/satim.png`	Shown beside the hotline message, on receipts and return pages
`cib-edahabia-logo.png`	`/vendor/satim/cib-edahabia-logo.png`	The button that sends the customer to SATIM

config('satim.receipt.logo') already points at the published SATIM logo, so receipts work with no further setup. Change it if you serve the file from somewhere else. Blanking it makes building a receipt fail rather than printing the hotline text alone.

Receipt carries orderId, orderNumber, approvalCode, paidAt, amount, amountInCentimes, currency, currencyLabel, maskedCard, cardholderName, message, paymentMethod, supportMessage, logo, and language, plus locale() and direction() for rendering.

Two things it enforces:

A rejected payment cannot have a receipt. Asking for one throws, so nothing that looks like proof of payment is ever produced for a payment that failed.
paymentMethod is the single label CIB/EDAHABIA. Both card types use the same terminal and the same flow, so there is no card type to detect.

Build the receipt once after confirming the payment, store it, and pass the stored date back later, because SATIM requires a reprint to be the original receipt, not a freshly dated one:

// First time.
$receipt = Satim::receipt($result);
$attempt->update(['receipt_issued_at' => $receipt->paidAt]);

// Any reprint, download, or email afterwards.
$receipt = Satim::receipt($result, paidAt: $attempt->receipt_issued_at);

supportMessage comes back in the receipt's language, defaulting to the configured one. For a multilingual site, build one receipt per language and store each.

Amount, Order Number, and `udf1`

Amount is given in dinars as int, float, or string, and converted to centimes for the gateway. Store your business amounts as DECIMAL(15,2); only the API boundary uses centimes. SATIM's minimum is 50 DA.
Order number must be exactly 10 alphanumeric characters and unique per attempt. The package validates the format; generating it and guaranteeing uniqueness against your own table is your responsibility. Use a bounded retry on collision. Note that SATIM itself accepts up to 10 characters; the fixed length is the stricter house rule this package enforces.
udf1 defaults to your orderNumber and is echoed back by SATIM on acknowledge, which makes it your reconciliation key. Override it with udf1: if your reference is something else. udf2–udf5 and fundingTypeIndicator (CP or 698) are optional; each udf value is capped at 20 characters.

Language

The configured language is used by default. Override it per call:

use GtsMeghni\Satim\Enums\SatimLanguage;

Satim::register(..., language: SatimLanguage::AR);

Audit Trail

SATIM may ask you months later what exactly was exchanged for a given payment. The package keeps that record: one row per gateway call, holding what was sent, what came back, and what it meant.

It is on by default, because the evidence has to exist before it is asked for. The package ships the migration, so all it needs is:

php artisan migrate

Every call is then recorded automatically, with nothing to add at your call sites.

To switch it off:

SATIM_AUDIT=false

To own the schema instead, publish the migration and tell the package to stop running its own copy, so the table is not created twice:

php artisan vendor:publish --tag="satim-migrations"

use GtsMeghni\Satim\SatimServiceProvider;

// In your AppServiceProvider::register()
SatimServiceProvider::ignoreMigrations();

What Gets Recorded

A row is written before the request leaves and completed when the answer arrives. That ordering is deliberate: a call that times out still leaves evidence, which is the case an audit most needs and most easily loses, because money may have moved without your application ever hearing back.

Rows are never edited afterwards, which is why there is no updated_at column. Credentials are redacted, so the stored request is safe to keep.

successful records the meaningful outcome rather than merely that a reply arrived: an order id for register, a paid transaction for confirm, and a zero error code for refund. A payment that was confirmed but rejected is therefore complete and not successful.

Reading an Order's History

use GtsMeghni\Satim\Models\SatimCall;

$state = SatimCall::stateFor($orderId);

$state->registered();             // SATIM accepted the order
$state->acknowledged();           // the outcome was confirmed, whatever it was
$state->paid();                   // the money was deposited
$state->refunded();               // at least one refund went through
$state->refundedInCentimes();     // total returned, across several partial refunds
$state->orderStatus();            // the last status SATIM reported
$state->unanswered();             // calls that never came back, worth chasing with SATIM
$state->calls;                    // every row, oldest first

There is no status column anywhere: an order's state is worked out from its rows, so nothing can drift out of step and a failed call is part of the picture rather than an absence.

The model also offers forOrder(), forOrderNumber(), operation(), successful(), and completed() for your own queries. The table is named in config('satim.audit.table').

What Stays Your Responsibility

The audit trail above covers the gateway exchange. Your own domain stays yours, and the package holds nothing about it: no customer, no basket, no invoice. Specifically:

The order number. Generating it, and guaranteeing it is unique against your own records before calling register(). Use a bounded retry on collision.
Linking a payment to whatever it is for, in your own tables. The audit rows carry only SATIM's identifiers, so join on order_number or order_id.
Your business amounts, stored as DECIMAL(15,2). Centimes exist only at the gateway boundary.
The receipt page, its PDF, and the email, from the contents Satim::receipt() gives you.

Every result object also exposes rawRequest and rawResponse, so you can store the payloads in your own tables instead of, or in addition to, the audit trail.

Changelog

Please see CHANGELOG for more information on what has changed recently.

Contributing

Thank you for considering contributing to Laravel Satim! Please review our contributing guide to get started.
