A rule-based firewall for outgoing requests made through Symfony's HttpClientInterface, configured somewhat like access_control for incoming ones: ordered rules, expressions, first match wins.

# config/packages/outgoing_firewall.yaml
outgoing_firewall:
    default: allow
    chains:
        require_ua:
            - { if: "headers['user-agent'] != 'my-app/1.0'", action: block }
        weekdays_only:
            - { if: "weekday in ['Sat', 'Sun']", action: block }
    rules:
        - { if: "host ends with '.example.com'", tag: external, jump: require_ua }
        - { if: "host == 'billing.example.com'", jump: weekdays_only }
        - { if: "tags.external and method != 'GET'", action: block }
        - { if: "ip_in(['10.0.0.0/8', '192.168.0.0/16'])", action: block, phase: connect }

A blocked request throws Valtzu\OutgoingFirewall\Http\RequestBlockedException (a TransportExceptionInterface) naming the rule that blocked it.

Purpose

This is a guard rail, not a security boundary.

It exists so that you don't shoot yourself in the foot: a staging deploy calling the production payment API, a test run hitting a real third party, a job talking to the wrong environment, a feature that must only run on weekdays. It protects against accidental cross-environment calls made by code you own.

It does not try to stop an attacker or a compromised vendor package from reaching something. Code that uses Guzzle, curl_*, file_get_contents() or a sockets directly never passes through Symfony's HttpClientInterface, so it is not seen. If you need real egress control, enforce it outside PHP (network policy, egress proxy, container or firewall rules).

Installation

composer require valtzu/symfony-outgoing-firewall

// config/bundles.php
Valtzu\OutgoingFirewall\ValtzuOutgoingFirewallBundle::class => ['all' => true],

By default the firewall decorates http_client.transport, the service every FrameworkBundle client ends up in (http_client and all scoped_clients). Because scoped clients merge their own options before reaching it, the rules see their headers and resolved URLs. Use transports to protect other services:

outgoing_firewall:
    transports: [http_client.transport, my_custom_client]

Rules

Rules run top to bottom. The first rule that decides (action: allow or action: block) wins. When none does, default applies.

A rule has a condition, if, and effects. The condition says when the rule applies, the effects say what happens then:

Key	Kind	Meaning
`if`	condition	When the rule applies: an expression or a map of matchers, see below. Omit it to always apply.
`action`	effect	`allow` or `block` decide the request. `log` flags it for the log and the profiler, then evaluation continues.
`tag`	effect	A tag, or a list of tags, to put on the request.
`jump`	effect	A chain, or a list of chains, to evaluate.
`phase`		`request` (default) or `connect`, see below.

A rule needs at least one effect. When a rule applies, it first adds its tags, then runs its jumps, then applies its action.

Conditions

if is one or the other: an expression, or a map of matchers for the common exact matches. They cannot be mixed in one rule. These two rules are the same:

- { if: { host: foo.com, path: /bar }, action: block }
- { if: "host == 'foo.com' and path == '/bar'", action: block }

Matcher	Matches
`method`, `scheme`, `host`, `port`, `path`	The variable of the same name, exactly
`tags`	The request carries the tag, see `tag` above

All matchers in the map must hold. A list means "any of": method: [POST, DELETE] is method in ['POST', 'DELETE'], and tags: [a, b] needs one of the two tags. Method, scheme and host are compared case-insensitively. The profiler shows the compiled expression. An unknown matcher fails when the container is built.

Anything the matchers cannot say needs an expression:

# tag a request, then act on the tag further down
- { if: { host: [api.example.com, billing.example.com] }, tag: external }
- { if: "tags.external and weekday in ['Sat', 'Sun']", action: block }

In an expression, a tag is tags.name (or tags['my-tag']), which is false for any tag not set. A literal % in an expression must be written %%, as in any container parameter.

Variables

Name	Value
`method`, `url`	Method and the full resolved URL
`scheme`, `host`, `port`, `path`, `query`	Parts of the resolved URL. `host` is lowercase.
`tags`	Tags set by earlier rules: `tags.name` is `true` or `false`
`headers`	Request headers, read as `headers['User-Agent']`: case-insensitive, several values joined with `,` , `null` when absent. Includes headers from `default_options`, scoped clients and `withOptions()`.
`extra`	The request's `extra` option, read as `extra['target']`, `null` when not set. See below.
`now`, `weekday`, `hour`	Current time (from the `clock` service), `Mon`..`Sun`, `0`..`23`
`ip`, `connect_time`	Peer IP and connect time in seconds, `null` until the connection is made (connect phase)

Functions

Name	Value
`ip_in(ranges)`	Whether `ip` is in a CIDR range or a list of them

Everything else from Symfony's ExpressionLanguage is available (matches, in, starts with, ends with, contains, now.format('H'), ...).

Telling your own requests apart

The firewall sees URLs and headers, not which part of your code made the request. To tell integrations apart, put a marker in Symfony's extra request option, which HttpClient passes along untouched. Setting it once on a client or scoped client tags everything that client sends:

framework:
    http_client:
        scoped_clients:
            billing.client:
                base_uri: https://billing.example.com
                extra: { target: billing }

- { if: "extra['target'] == 'billing' and weekday in ['Sat', 'Sun']", action: block }

Chains

A chain is a named list of rules, so that several hosts can share one set without repeating it. jump evaluates a chain. If a rule inside it decides, that decides the request. If nothing in it decides, evaluation continues after the jump rule (like RETURN in iptables). Chains may jump to other chains. Unknown chains and cycles fail when the container is built.

outgoing_firewall:
    chains:
        business_hours:
            - { if: "weekday in ['Sat', 'Sun']", action: block }
            - { if: "hour < 8 or hour >= 18", action: block }
    rules:
        - { if: "host == 'api.example.com'", jump: [business_hours] }
        - { if: "host == 'billing.example.com'", jump: [business_hours] }

A chain can also be written with a phase that all its rules inherit:

chains:
    no_private_ips:
        phase: connect
        rules:
            - { if: "ip_in('10.0.0.0/8')", action: block }

Phases

Most rules only need what is known before sending: URL, headers, time. These run in the request phase and block by throwing from request().

The peer IP and the connect time are only known once the connection is made. Rules with phase: connect run once, from the client's on_progress callback, when the transport first reports the peer IP. The callback is installed only when at least one connect rule exists, and any on_progress you pass is still called.

Things to know:

A connect-phase block aborts the transfer, and the exception comes out when the response is consumed (getStatusCode(), getContent()), not from request().
The connection is already open then, so the request may already have been sent. Use the request phase for anything that must not leave your process.
jump rules without an explicit phase run in both phases, so a jump into a connect chain works from a top-level rule.
connect_time is reported by the curl transport only. With the native transport it stays null.
If the transport never reports a peer IP (MockHttpClient for instance), connect rules never run. That includes default: block.

Logging

Blocked requests are logged at warning, and requests that matched an action: log rule at info. Both go to the outgoing_firewall channel, with the method, the URL without its query string, the tags and, for blocks, the rule that decided. Allowed requests are not logged unless a rule says log, so this is cheap to leave on in production.

# config/packages/monolog.yaml
monolog:
    handlers:
        outgoing_firewall:
            type: stream
            path: '%kernel.logs_dir%/outgoing_firewall.log'
            level: info
            channels: [outgoing_firewall]

A rule that only watches, without changing the outcome:

- { if: { host: api.payments.example }, action: log }

Profiler

With symfony/web-profiler-bundle and kernel.debug, the toolbar shows how many requests were blocked or logged. The panel lists those requests, the rules evaluated for each, which ones matched, the tags collected and the variables. Allowed requests are left out, to keep the panel readable. Add action: log to a rule to see its requests here as well.

Extending

Add variables by implementing VariableProviderInterface and tagging the service outgoing_firewall.variable_provider (autoconfigure is not enabled for it):

final class DeploymentVariables implements VariableProviderInterface
{
    public function getVariables(): array
    {
        return ['env' => $_SERVER['APP_ENV']];
    }
}

- { if: "env != 'prod' and host == 'api.payments.example'", action: block }

Custom variables are available in expressions only. The map form of if knows just the built-in matchers.

Add functions with Symfony's ExpressionFunctionProviderInterface, tagged outgoing_firewall.expression_function_provider.

Testing

composer install
vendor/bin/phpunit

License

MIT. The profiler icon is from Tabler Icons (MIT).
