lindemannrock/craft-formie-rest-api

REST API for Formie - Provides REST endpoints for accessing Formie forms and submissions

3.4.0 2026-05-06 09:19 UTC

Requires

• php: ^8.2
• craftcms/cms: ^5.0.0
• guzzlehttp/guzzle: ^7.0
• lindemannrock/craft-plugin-base: ^5.0
• verbb/formie: ^3.0.0

Requires (Dev)

• craftcms/ecs: dev-main
• craftcms/phpstan: dev-main

proprietary

• Bilal Hary Lindemann

• api
• cms
• REST API
• Craft
• craftcms
• craft-plugin
• formie

README

A REST API plugin for Craft CMS that exposes Formie forms and submissions through authenticated REST endpoints. Designed for external systems (e.g. SAP, BI tools, partner integrations) that need structured form data over HTTP.

Note on GraphQL: Formie ships with its own GraphQL schema at Craft's /api endpoint. This plugin does not add GraphQL — it adds a separate REST API with its own auth (X-API-Key), rate limiting, and access logging. If you want GraphQL, use Formie's built-in support directly.

License

This is a commercial plugin licensed under the Craft License. It will be available on the Craft Plugin Store soon. See LICENSE.md for details.

⚠️ Pre-Release

This plugin is in active development and not yet available on the Craft Plugin Store. Features and APIs may change before the initial public release.

Requirements

• Craft CMS 5.0 or greater
• PHP 8.2 or greater
• Formie 3.0 or greater

Overview

The Formie REST API plugin provides:

• REST endpoints for forms and submissions
• API-key authentication via X-API-Key header (Primary, Limited, Test)
• Rate limiting with X-RateLimit-* response headers and 429 on exceed
• Access logging for every request (partial key fingerprint, endpoint, IP, status)
• CLI key generator (ddev craft formie-rest-api/security/generate-key)
• In-CP test page for verifying keys, endpoints, and filters without leaving Craft
• Postman collection (in postman/) with auto-HMAC pre-request script
• Translated CP UI — 12 languages (EN, DE, FR, NL, ES, IT, PT, AR, JA, SV, DA, NO)

Installation

Via Composer

cd /path/to/project

composer require lindemannrock/craft-formie-rest-api

./craft plugin/install formie-rest-api

Using DDEV

cd /path/to/project

ddev composer require lindemannrock/craft-formie-rest-api

ddev craft plugin/install formie-rest-api

Via Control Panel

In the Control Panel, go to Settings → Plugins and click "Install" for Formie REST API.

Environment Configuration

The plugin reads API keys from environment variables (or, optionally, config/general.php):

# Primary API key — full read/write access
FORMIE_API_KEY="..."

# Limited access key — read forms only (optional)
FORMIE_API_KEY_LIMITED="..."

# Test key — only valid when devMode=true (optional, local only)
FORMIE_API_KEY_TEST="..."

Use different values per environment (local, staging, production). Never share keys across environments.

Generating keys

A console command generates secure keys and (optionally) writes them to .env:

# Local
ddev craft formie-rest-api/security/generate-key

# Staging / production (run on the server)
php craft formie-rest-api/security/generate-key

The command:

1. Asks which key to generate — primary, limited, test, or all (generates all three in turn, sharing the same prefix; test is auto-skipped if devMode is off)
2. Asks for a prefix — defaults to fra_, type - for none, or supply a custom prefix
3. Prints the generated key (prefix + 64 hex chars)
4. Warns and confirms before replacing an existing key (avoids surprise 401s for live consumers)
5. Offers to also generate a paired HMAC signing secret (presence of the matching FORMIE_API_SIGNING_SECRET[_*] env var auto-enables required-signature mode for that key — see HMAC Request Signing)
6. Asks whether to write to .env:
   • Yes → writes one consolidated block per key type (# Formie REST API — Primary / Limited / Test, key + secret co-located). Re-running the command for the same key cleans up any legacy scattered entries it owns and replaces them with the fresh block.
   • No → prints the block so you can paste it into a hosting panel (Servd, Forge, Cloudways, etc.) or a secrets store

Test keys are refused (when chosen explicitly) or skipped (in all mode) unless devMode=true.

When an existing signing secret is detected, the command asks whether to rotate it or keep it — so you can rotate just the API key without invalidating signed clients.

Authentication

REST API Authentication

Include API key in request headers:

curl -H "X-API-Key: your-api-key-here" https://yoursite.com/api/v1/formie/forms

HMAC Request Signing (optional, recommended for production)

For production keys, the plugin supports HMAC-SHA256 request signing. Signing adds:

• Replay protection — captured requests expire after a 5-minute timestamp window
• Tamper detection — the signature covers method, path, timestamp, and body
• Defence-in-depth — a leaked API key alone is no longer sufficient; the attacker also needs the separate signing secret

Enable per key by setting the matching env var (presence of the env var auto-enables the requirement on that key):

FORMIE_API_SIGNING_SECRET="..."           # paired with FORMIE_API_KEY
FORMIE_API_SIGNING_SECRET_LIMITED="..."   # paired with FORMIE_API_KEY_LIMITED
FORMIE_API_SIGNING_SECRET_TEST="..."      # paired with FORMIE_API_KEY_TEST (devMode only)

ddev craft formie-rest-api/security/generate-key offers to generate the paired signing secret at the end of the key-generation flow.

Required headers when signing is enabled:

Header	Value
X-API-Key	The API key (as before)
X-Timestamp	Current Unix epoch seconds
X-Signature	Hex HMAC-SHA256 of the signature base, keyed by the signing secret

Signature base (joined with literal \n):

METHOD\nPATH_WITH_QUERY\nTIMESTAMP\nBODY

For a GET /api/v1/formie/forms request the body is empty.

Example client (bash):

KEY="fra_..."
SECRET="..."
TS=$(date +%s)
PATH_Q="/api/v1/formie/forms"
SIG=$(printf "GET\n%s\n%s\n" "$PATH_Q" "$TS" | openssl dgst -sha256 -hmac "$SECRET" -hex | awk '{print $NF}')

curl -H "X-API-Key: $KEY" \
     -H "X-Timestamp: $TS" \
     -H "X-Signature: $SIG" \
     "https://yoursite.com$PATH_Q"

Example client (PHP):

$key = getenv('FORMIE_API_KEY');
$secret = getenv('FORMIE_API_SIGNING_SECRET');
$path = '/api/v1/formie/forms';
$ts = (string) time();
$sig = hash_hmac('sha256', "GET\n{$path}\n{$ts}\n", $secret);

// Send X-API-Key, X-Timestamp, X-Signature headers

Postman collection

A ready-to-use Postman collection lives in postman/ — collection plus three environment templates (Primary, Limited, Test). The collection-level pre-request script computes the HMAC signature automatically when signing_secret is set on the active environment, and skips it when empty (for keys without signing). See postman/README.md for setup.

IP Whitelist (optional, defence-in-depth)

Restrict which client IPs can use a given API key. Useful for server-to-server integrations on stable infrastructure (SAP, ERP, internal networks).

Enable per key by setting the matching env var to a comma-separated list of IPs and/or CIDR ranges (presence of the env var auto-enables the restriction):

FORMIE_API_IP_WHITELIST="203.0.113.5,192.168.1.0/24,2001:db8::/32"
FORMIE_API_IP_WHITELIST_LIMITED="..."
FORMIE_API_IP_WHITELIST_TEST="..."

Empty/unset env → no IP restriction (request accepted from any IP). Non-matching IP → 401 Unauthorized with message Request originates from an IP not allowed for this key.

Supports IPv4 and IPv6. Single IPs (203.0.113.5, 2001:db8::1) and CIDR ranges (192.168.1.0/24, 2001:db8::/32).

CDN / reverse-proxy caveat: Craft::$app->request->getUserIP() returns whatever sent the request to PHP. Behind a CDN or reverse proxy you'll need to configure Craft's trustedHosts and proxy headers correctly — otherwise the whitelist matches the proxy IP, not the real client. See Craft's request docs for trustedHosts setup.

CORS support — not currently implemented

This plugin does not add Access-Control-Allow-* response headers and does not handle OPTIONS preflight requests. The API is currently designed for server-to-server consumers (your SAP/ERP integration, scripts, scheduled jobs) where CORS does not apply.

This means a browser-based client on a different origin (a React/Vue dashboard, a partner widget, etc.) cannot call this API directly. The browser will block the response with a CORS error.

If you need browser access today, the workaround is to proxy the request through your own server (your backend calls this API with X-API-Key and forwards the response to the browser).

CORS is on the roadmap as an opt-in, env-driven feature mirroring the HMAC and IP-whitelist patterns (per-key FORMIE_API_ALLOWED_ORIGINS[_*] env var). It will be implemented when the first browser consumer's requirements are known. Open an issue if you need it sooner.

Field metadata — units & notes

Field metadata returned by /forms/{id|handle} reflects Formie's own settings. A few values where the unit isn't obvious:

Field type	Setting	Unit
FileUpload	sizeLimit, sizeMinLimit	Megabytes (MB)
FileUpload	limitFiles	Number of files
Signature	penWeight	Pixels
SingleLineText / MultiLineText	min, max	See minType / maxType (characters or words)
Date	minDateOffsetNumber, maxDateOffsetNumber	See minDateOffsetType / maxDateOffsetType (days, weeks, months, years)
Date	minYearRange, maxYearRange	Years offset from current year (e.g. -100 = 100 years ago, 100 = 100 years ahead)

All datetime values across submission and field-value responses are ISO 8601 in the site timezone.

Submission filtering (default behaviour)

Both production (/api/v1/formie/submissions) and test (/api/test/formie/submissions) endpoints automatically exclude:

• Incomplete submissions — abandoned drafts that were never finalised (isIncomplete = true)
• Spam submissions — anything Akismet or another captcha integration flagged (isSpam = true)

This is hardcoded — the API contract is "completed, non-spam form submissions". There is currently no opt-in flag to include drafts or spam. If your integration needs them, open an issue describing the use case.

REST API Endpoints

Versioning

The plugin uses two independent version axes — they don't move together:

Version	Tracks	Bumps when
Plugin (e.g. 3.3.0)	This package's release	Every feature/fix. Plugin major aligns to the Formie major (Formie 3.x → plugin 3.x.x; Formie 4 → plugin 4.0.0)
API URL (/api/v1/)	The wire-format contract consumers integrate against	Only on breaking contract changes (removed/renamed fields, changed semantics). Plugin major bumps do not automatically bump the API URL

Branch strategy. When Formie ships a new major, main tracks the new major (e.g. plugin 4.x for Formie 4), and the previous Formie major lives on a maintenance branch (e.g. 3.x) for security and critical fixes during a deprecation window. The /api/vN/ URL stays the same across these branches as long as the wire format is unchanged — so an integrator targeting /api/v1/ keeps working whether the site is on plugin 3.x or 4.x.

Production Endpoints

Method	Endpoint	Description
GET	/api/v1/formie/forms	List all forms
GET	/api/v1/formie/forms/{id}	Get form by ID
GET	/api/v1/formie/forms/{handle}	Get form by handle
GET	/api/v1/formie/submissions	List submissions
GET	/api/v1/formie/submissions/{id}	Get submission details

Test Endpoints (Development)

Method	Endpoint	Description
GET	/api/test/formie/forms	Test forms endpoint
GET	/api/test/formie/submissions	Test submissions endpoint
GET	/api/test/formie/auth	Test authentication

Example Usage

REST API Examples

# List all forms
curl -H "X-API-Key: your-api-key" \
     https://yoursite.com/api/v1/formie/forms

# Get specific form by handle
curl -H "X-API-Key: your-api-key" \
     https://yoursite.com/api/v1/formie/forms/contactForm

# Get form submissions
curl -H "X-API-Key: your-api-key" \
     "https://yoursite.com/api/v1/formie/submissions?form=contactForm&limit=10"

API Documentation

• postman/ — Postman collection + environment templates with auto-HMAC pre-request script
• .env.example — Environment variable configuration
• In-CP Test tab — live API tester at Settings → Plugins → Formie REST API → Test

API Key Permissions

Key Type	Permissions	Rate Limit
Primary	Read forms, Read submissions	1000/hour
Limited	Read forms only	100/hour
Test	Full access (dev mode only)	Unlimited

Two permission systems — don't confuse them

The plugin has two separate permission systems with different audiences. Both are called "permissions" but they don't overlap.

	Craft user permissions	API key scopes
Audience	Logged-in CP users (humans)	External clients with X-API-Key
Where defined	Code → EVENT_REGISTER_PERMISSIONS	Code → ApiKeyService::getValidApiKeys()
Where assigned	CP → Settings → Users → User Groups → "Formie REST API" section	Hardcoded per env-var (Primary / Limited / Test)
What's enforced	Manage settings (gates the CP settings page)	read_forms, read_submissions, create_submissions (gates each REST endpoint)
Failure status	403 from CP redirect / login	403 ForbiddenHttpException from API

In practice:

• A CP user with Manage settings can edit the plugin's settings page. That's all the CP grants.
• An external API consumer's access is determined entirely by which env-var slot their API key was generated into:
  • FORMIE_API_KEY → Primary scope (full read)
  • FORMIE_API_KEY_LIMITED → Limited scope (forms only)
  • FORMIE_API_KEY_TEST → Test scope (full read, devMode only)

If you give a partner a Limited key thinking they can't read submissions — they can't. The scope is enforced server-side.

Security Features

• API key validation (per-key permission scopes: read_forms, read_submissions, create_submissions)
• HMAC request signing (optional, opt-in per key — replay protection, integrity, leaked-key mitigation)
• IP whitelist (optional, opt-in per key — IPv4 + IPv6 + CIDR)
• Rate limiting per key (atomic, mutex-serialized counter)
• Access logging (key, endpoint, IP, user-agent, response code)
• Development-mode restrictions (test endpoints + test key only register when devMode = true)
• Not yet: CORS for browser consumers — see CORS support — not currently implemented

Operational hardening (Craft-level, not plugin-level)

A couple of Craft framework settings worth knowing about — the plugin doesn't control these, but they affect API responses:

• X-Powered-By: Craft CMS response header. Craft sends this by default. Some security-conscious deployments prefer to suppress it (defence in depth — don't tell unfamiliar attackers what stack to research). Disable it in config/general.php:

  return GeneralConfig::create()
      ->sendPoweredByHeader(false);

• Server: nginx / similar. Set at the web server level, not Craft. Strip via server_tokens off; (nginx) or equivalent.

• trustedHosts / proxy headers. If you put the API behind a CDN or reverse proxy and use the IP whitelist feature, configure Craft's trustedHosts correctly so getUserIP() returns the real client IP, not the proxy. See Craft docs.

Plugin Settings

Navigate to Settings → Plugins → Formie REST API for:

• General — plugin name (overridable via config/formie-rest-api.php)
• Test — live API tester: pick a configured key, choose an endpoint, set optional filters (form handle, date range, limit/offset), and view the response status, headers, body, and the equivalent curl command. Available regardless of devMode; test endpoints (/api/test/formie/*) only resolve when devMode = true.

Support

• Documentation: https://github.com/LindemannRock/craft-formie-rest-api
• Issues: https://github.com/LindemannRock/craft-formie-rest-api/issues
• Email: [e-mail]

License

This plugin is licensed under the Craft License. See LICENSE.md for details.

Developed by LindemannRock

Built for use with Formie by Verbb
