README

Laravel Rough Notation

Beautiful hand-drawn animations for Laravel. A lightweight Rough Notation wrapper to circle, underline, and highlight elements in your Blade and Livewire applications.

Features

Fluent Notation:: builder for creating annotations
Blade directives: @annotate, @endannotate, and @roughNotationScripts
Supports types: underline, box, circle, highlight, strike-through, crossed-off, bracket
Options: color, strokeWidth, padding, iterations, brackets, animationDuration
Group multiple annotations to animate in sequence

Installation

composer require amjadiqbal/laravel-rough-notation

Interactive Install

Run the guided installer:

php artisan rough:install

Options:

--cdn=true|false to select CDN vs local
--publish-assets=true|false to download local ESM script
--assets-path=public/vendor/rough-notation to pick destination path
--open-link=true to open support/contact page

Example:

php artisan rough:install --cdn=false --publish-assets=true --assets-path=public/vendor/rough-notation

Publish Config and Assets

Publish the package config:

php artisan vendor:publish --tag=rough-notation-config

Publish local ESM script:

php artisan rough:publish-assets --path=public/vendor/rough-notation

Quick Start

Install: composer require amjadiqbal/laravel-rough-notation
Guided install: php artisan rough:install
Publish config: php artisan vendor:publish --tag=rough-notation-config
Publish local ESM: php artisan rough:publish-assets --path=public/vendor/rough-notation
Add scripts: @roughNotationScripts
Annotate with directives, components, or the builder API

Setup

Add scripts to your layout:

@roughNotationScripts

Configuration (optional) published to config/rough-notation.php:

return [
    'assets' => [
        'cdn' => true,
        'module_url' => 'https://unpkg.com/rough-notation?module',
        'local' => [
            'public_url' => '/vendor/rough-notation',
            'module' => 'rough-notation.esm.js',
        ],
    ],
];

Requirements

PHP 8.1+
Laravel 11

Example Layout

<!-- resources/views/layouts/app.blade.php -->
<!doctype html>
<html lang="en">
<head>
  <meta charset="utf-8">
  <meta name="viewport" content="width=device-width, initial-scale=1">
  <title>Rough Notation Demo</title>
</head>
<body>
  @yield('content')
  @roughNotationScripts
</body>
</html>

Usage

Wrap any text or element:

@annotate('circle', ['color' => '#ff0055']) Important Text @endannotate

With options:

@annotate('highlight', ['color' => '#fff59d', 'padding' => 6]) Highlighted @endannotate

Groups:

@annotate('underline', [], 'hero') First @endannotate
@annotate('box', ['padding' => 8], 'hero') Second @endannotate
@annotate('circle', ['color' => 'red'], 'hero') Third @endannotate

Chainable API (Non-Blade)

use AmjadIqbal\RoughNotation\Notation;

echo Notation::make('circle')
    ->color('red')
    ->strokeWidth(3)
    ->group('hero')
    ->render('Important Text');

Blade Component

Basic component:

<x-annotate type="circle" :options="['color' => 'red']">Important</x-annotate>

Typed components (namespaced):

<x-rough-notation::circle :options="['color' => 'red']">Circled</x-rough-notation::circle>
<x-rough-notation::underline>Underlined</x-rough-notation::underline>
<x-rough-notation::box :options="['padding' => 8]">Boxed</x-rough-notation::box>
<x-rough-notation::highlight :options="['color' => '#fff59d']">Highlighted</x-rough-notation::highlight>
<x-rough-notation::strike-through>Struck</x-rough-notation::strike-through>
<x-rough-notation::crossed-off>Crossed</x-rough-notation::crossed-off>
<x-rough-notation::bracket :options="['brackets' => ['left','right']]">Bracketed</x-rough-notation::bracket>

Props:

options: array of supported options
group: string group id to sequence annotations
tag: wrapper tag (defaults to span)

Demo Page

// routes/web.php
use Illuminate\Support\Facades\Route;
Route::view('/rough-demo', 'rough-demo');

<!-- resources/views/rough-demo.blade.php -->
@extends('layouts.app')

@section('content')
  <div style="display:grid; gap:16px; padding:24px;">
    @annotate('underline') Underline @endannotate
    @annotate('box', ['padding' => 8]) Boxed @endannotate
    @annotate('circle', ['color' => 'red']) Circled @endannotate
    @annotate('highlight', ['color' => '#fff59d']) Highlighted @endannotate
    @annotate('strike-through') Struck @endannotate
    @annotate('crossed-off') Crossed @endannotate
    @annotate('bracket', ['brackets' => ['left','right']]) Bracketed @endannotate
    @annotate('underline', [], 'hero') Step 1 @endannotate
    @annotate('box', ['padding' => 8], 'hero') Step 2 @endannotate
    @annotate('circle', ['color' => 'red'], 'hero') Step 3 @endannotate
  </div>
@endsection

Types Gallery

Each example shows the directive and a short description.

underline:

@annotate('underline') Underline @endannotate

box:

@annotate('box', ['padding' => 8]) Boxed @endannotate

circle:

@annotate('circle', ['color' => 'red']) Circled @endannotate

highlight:

@annotate('highlight', ['color' => '#fff59d']) Highlighted @endannotate

strike-through:

@annotate('strike-through') Struck @endannotate

crossed-off:

@annotate('crossed-off') Crossed @endannotate

bracket:

@annotate('bracket', ['brackets' => ['left', 'right']]) Bracketed @endannotate

Livewire Usage

The scripts directive auto re-initializes after Livewire updates.
For manual re-init:

window.initRoughNotation();

Testing

vendor/bin/pest

Examples

Livewire: call window.initRoughNotation() after component updates to re-init annotations on dynamic content.
Multiple groups: mix sequences by assigning different group ids to elements.
Local assets: after php artisan rough:publish-assets, set cdn to false in config to import the local ESM.

Options Reference

color: string color or hex
strokeWidth: int line width
padding: int inner padding in px
iterations: int number of sketch strokes
animationDuration: int in ms
brackets: array|string (left|right|top|bottom) only for type=bracket

Screenshots

Contributing

Follow PSR-12 code style
Run tests before submitting changes
Open a PR with a clear description

Changelog

See CHANGELOG.md.

License

MIT License. See LICENSE.

Author

Amjad Iqbal — amjad.com.pk · hi@amjad.com.pk · GitHub
