studio255/yii2-jstree

Yii2 widget wrapping the jsTree jQuery library — displays and manages ActiveRecord models as interactive trees.

v1.0.18 2026-06-06 16:25 UTC

Requires

• php: >=8.2
• bower-asset/jstree: ^3.3
• yiisoft/yii2: ^2.0.51

MIT

• Studio255 Karlsruhe

• tree
• ui
• widget
• jstree
• yii2
• yii2-extension
• treeview

README

A Yii2 widget for the jsTree jQuery library — display and manage Yii2 ActiveRecord models as interactive trees.

Features

• Load tree data via AJAX
• Custom icons per node type (FontAwesome, Bootstrap Icons, or any CSS class)
• Context menu: create, rename, duplicate, delete
• Drag-and-drop reordering
• Submenu with individual node types
• Dynamic context menu — hide items per node type (e.g. no delete on type page)
• Customizable labels and confirmation messages
• Yii2 validation errors forwarded to JavaScript alerts

Requirements

• PHP 8.2 or higher
• Yii2 2.0.51 or higher

Installation

composer require studio255/yii2-jstree

Usage

Simple variant — JSON URL only

$tree = new \studio255\jstree\JsTree([
    'jsonUrl' => '/my-json-url/data',
]);

<div id="jstree"></div>

Full variant — backed by a Yii2 ActiveRecord model

Enables create, move, rename and delete operations on the model directly from the tree.

Required model / database fields:

Field	Required	Purpose
name	yes	Display label
parent_id	yes	Tree nesting
position	yes	Sort order within parent
type	no	Used for icon and permission handling

Important: Only name should be a required attribute in your model — otherwise the New context menu action may fail.

Controller setup:

public function actionIndex()
{
    $tree = new \studio255\jstree\JsTree([
        'modelName'             => 'backend\\models\\YourModel',
        'modelPropertyId'       => 'id',
        'modelPropertyParentId' => 'parent_id',
        'modelPropertyPosition' => 'position',
        'modelPropertyName'     => 'name',
        'modelFirstParentId'    => null,
        'modelPropertyType'     => 'type',
        'controllerId'          => 'index',
        'jstreeDiv'             => '#jstree',
        'jstreeIcons'           => false,
        'jstreePlugins'         => ['contextmenu', 'dnd'],
        'jstreeContextMenue'    => [
            'remove' => ['text' => 'Delete', 'icon' => 'fa fa-trash'],
            'edit'   => ['text' => 'Edit',   'icon' => 'fa fa-pencil'],
            'create' => [
                'text'    => 'Create new',
                'icon'    => 'fa fa-plus',
                'type'    => 'online',
                'submenu' => [
                    ['text' => 'New offline node', 'icon' => 'fa fa-cloud',      'type' => 'offline'],
                    ['text' => 'New online node',  'icon' => 'fa fa-cloud-bolt', 'type' => 'online'],
                ],
            ],
            'rename' => ['text' => 'Rename', 'icon' => 'fa fa-i-cursor'],
        ],
        'jstreeType' => [
            '#'       => ['max_children' => -1, 'max_depth' => -1, 'valid_children' => -1, 'icon' => 'fa fa-list'],
            'default' => ['icon' => 'fa fa-question'],
        ],
        'jstreeMsg' => [
            'confirmdelete' => 'Are you sure you want to delete this item?',
            'nothere'       => 'Not allowed at this position.',
        ],
    ]);

    return $this->render('index');
}

View setup:

A click on a tree item triggers the update action via AJAX and loads the result into .jstree-result. Forms used inside the result div should carry the class jstree-form so their submit response is routed back to the result container.

<div id="jstree"></div>
<div class="jstree-result"></div>

The icon classes in the examples use FontAwesome — any CSS-based icon set works (Bootstrap Icons, Material, custom classes).

Demo

A working demo setup is available in the demo/ directory.

License

MIT — see LICENSE.
