README

A self-hosted image transformation service.

Put your original images in a directory, start one Docker container, then resize, crop and convert them by changing the URL.

/image/upload/c_fill,w_640,h_360/demo.jpg

No upload API. No database. No configuration file.

EvaThumber keeps your originals untouched and generates everything else on demand.

See it

The demo image is 5184×3456. EvaThumber never emits anything larger than 4096 pixels on a side, so the picture below is the file as it sits in your images directory. It is not something you can fetch back through a transformation URL.

Resize to 600px wide:

/image/upload/w_600/demo.jpg

Crop it to a 600×300 image:

/image/upload/c_fill,w_600,h_300/demo.jpg

Turn it into a square:

/image/upload/c_fill,w_400,h_400/demo.jpg

Keep the whole image and fit it inside 600×300:

/image/upload/c_fit,w_600,h_300/demo.jpg

Add a white canvas instead of cropping:

/image/upload/c_pad,w_600,h_300,b_white/demo.jpg

Convert to grayscale:

/image/upload/w_600/e_grayscale/demo.jpg

Convert to WebP with automatic quality:

/image/upload/w_600/q_auto/f_webp/demo.jpg

Transformations can be chained:

/image/upload/c_fill,w_600,h_300/e_grayscale/q_80/f_webp/demo.jpg

That is basically how EvaThumber works.

Run it

Mount the directory containing your original images:

docker run \
  -p 8080:8080 \
  -v /path/to/your/images:/data/images:ro \
  docker.io/allovince/evathumber

If /path/to/your/images/demo.jpg exists, open:

http://localhost:8080/image/upload/w_600/demo.jpg

The image is generated on the first request and cached afterwards.

The original directory is mounted read-only. EvaThumber never modifies your source images.

Cache

Generated images are cached in /data/cache.

You do not have to configure it.

With the command above, the cache lives inside the container. Removing the container effectively clears all generated images. They will simply be generated again when requested.

If you want the cache to survive container replacement, mount it:

docker run \
  -p 8080:8080 \
  -v /path/to/your/images:/data/images:ro \
  -v evathumber-cache:/data/cache \
  docker.io/allovince/evathumber

The cache contains derived data only. It does not need to be backed up.

URL

EvaThumber uses Cloudinary-style transformation URLs:

/image/upload/{transformations}/{public_id}.{ext}

It also accepts the Cloudinary form with a cloud name:

/{cloud_name}/image/upload/{transformations}/{public_id}.{ext}

Parameters inside one transformation are separated by commas:

c_fill,w_600,h_400

Multiple transformations are separated by /:

c_fill,w_600,h_400/e_grayscale/q_80/f_webp

So:

/image/upload/c_fill,w_600,h_400/e_grayscale/q_80/f_webp/demo.jpg

means:

    ↓
fill 600×400
    ↓
grayscale
    ↓
quality 80
    ↓
WebP

Transformations

Resize

Resize by width:

/image/upload/w_600/demo.jpg

Resize by height:

/image/upload/h_400/demo.jpg

Relative size:

/image/upload/w_0.5/demo.jpg

Crop and fit

Scale:

/image/upload/c_scale,w_600/demo.jpg

Fit inside a box without cropping:

/image/upload/c_fit,w_600,h_300/demo.jpg

Fill a box and crop overflow:

/image/upload/c_fill,w_600,h_300/demo.jpg

Crop:

/image/upload/c_crop,w_600,h_400,g_center/demo.jpg

Thumbnail:

/image/upload/c_thumb,w_400,h_400,g_center/demo.jpg

Pad:

/image/upload/c_pad,w_600,h_300,b_white/demo.jpg

Limit an image without enlarging it:

/image/upload/c_limit,w_1600,h_1600/demo.jpg

Gravity

/image/upload/c_fill,w_400,h_400,g_north/demo.jpg
/image/upload/c_fill,w_400,h_400,g_south/demo.jpg
/image/upload/c_fill,w_400,h_400,g_east/demo.jpg
/image/upload/c_fill,w_400,h_400,g_west/demo.jpg

Compass gravity is supported:

center
north
north_east
east
south_east
south
south_west
west
north_west

Aspect ratio

/image/upload/c_fill,w_600,ar_16:9/demo.jpg

DPR

/image/upload/c_fill,w_300,h_200,dpr_2/demo.jpg

The resulting image is rendered at 600×400 pixels.

Rotate and flip

/image/upload/w_600/a_90/demo.jpg
/image/upload/w_600/a_180/demo.jpg
/image/upload/w_600/a_hflip/demo.jpg
/image/upload/w_600/a_vflip/demo.jpg

Effects

/image/upload/w_600/e_grayscale/demo.jpg
/image/upload/w_600/e_negate/demo.jpg

Quality

Explicit quality:

/image/upload/w_600/q_80/demo.jpg

Automatic quality:

/image/upload/w_600/q_auto/demo.jpg
/image/upload/w_600/q_auto:best/demo.jpg
/image/upload/w_600/q_auto:good/demo.jpg
/image/upload/w_600/q_auto:eco/demo.jpg
/image/upload/w_600/q_auto:low/demo.jpg

q_auto is EvaThumber's local content-adaptive heuristic. It is not Cloudinary's proprietary perceptual algorithm.

Output size limit

The result of every request must fit within 4096 pixels on each side and 16 megapixels in total. Rotation, flipping, effects and quality settings do not change the pixel count, so applying them on their own to a large original is rejected with 413 image_too_large. Resize in the same request, as in every example above.

Format

The URL extension can choose the output format:

/image/upload/w_600/demo.webp

Or use f_:

/image/upload/w_600/f_webp/demo.jpg
/image/upload/w_600/f_avif/demo.jpg
/image/upload/w_600/f_png/demo.jpg

Automatic format negotiation is also supported:

/image/upload/w_600/f_auto/demo.jpg

EvaThumber uses the request's Accept header to choose the output format.

Supported formats

Input:

JPEG
PNG
WebP
AVIF
GIF (static only)

Output:

JPEG
PNG
WebP
AVIF
GIF

What EvaThumber does not do

EvaThumber 2 deliberately keeps its scope small.

It does not currently implement:

remote or S3 image sources
animated image processing
SVG or PDF
text and image overlays
face detection
automatic AI gravity
rounded corners
blur, sharpen and other stylized effects
video transformation
upload or administration APIs

Unsupported transformations fail explicitly instead of being silently approximated.

Production behavior

EvaThumber 2 is built on PHP 8.5, FrankenPHP and libvips.

The Docker image:

supports linux/amd64 and linux/arm64
runs as a non-root user
keeps source images read-only
publishes cached files atomically
deduplicates concurrent generation of the same image
uses bounded work queues under load
returns 503 instead of allowing overload to corrupt images or exhaust the process
supports ETag, Last-Modified and conditional 304 responses
exposes /healthz and /readyz

The default configuration is intended to work without tuning.

If you need to know exactly how it behaves under load or process failure, see bench/ and docs/. The repository contains the benchmark and crash-recovery evidence used for the 2.0 release.

Using it as a PHP library

The transformation engine can also be used without the HTTP service:

use EvaThumber\Image\Pipeline;
use EvaThumber\Source\LocalSource;
use EvaThumber\Transformation\Parser;

$source = (new LocalSource('/path/to/images'))->resolve('demo');

(new Pipeline())->write(
    $source,
    (new Parser())->parse('c_fill,w_600,h_400'),
    '/tmp/demo.webp',
    'webp'
);

The library core does not depend on the HTTP cache or server layer.

Development

composer install
composer test
composer analyse

See docs/ for architecture, testing and release documentation.

From EvaThumber 1.x

EvaThumber started in 2012 as a small PHP image thumbnail library.

Version 2 is a complete rewrite. The basic idea is still the same:

change the URL, get the image you need.

The URL syntax, processing engine and deployment model have changed.

See docs/migration-v1.md.

License

BSD-3-Clause. See LICENSE.

Demo image

demo.jpg uses Lake Mountain Landscape by Bonnie Moreland, released under CC0 / public domain.

Source: Wikimedia Commons.
