README

This package provides a handful of tools to work with coordinates the same way as Google Maps Javascript API does.

Requires PHP 8.3+

Classes

LatLng class

A LatLng is a point in geographic coordinates: latitude and longitude. Both parameters are of float type.

Latitude ranges between -90 and 90 degrees inclusive. Values above or below this range will be clamped to the range [-90, 90]. This means that if the specified value is less than -90, it will be set to -90. And if the value is greater than 90, it will be set to 90.
Longitude ranges between -180 and 180 degrees inclusive. Values above or below this range will be adjusted to fit within the range. For example, a value of -190 will become 170. A value of 190 will become -170. This reflects the fact that longitudes wrap around the globe.

LatLngAltitude class

A LatLngAltitude is a 3D point in geographic coordinates: latitude, longitude, and altitude.

Altitude is measured in meters. Positive values indicate heights above ground level, and negative values indicate depths below the ground surface.

LatLngBounds class

A LatLngBounds instance represents a rectangle in geographical coordinates, including one that crosses the 180-degree longitudinal meridian.

Features

Movement

Both LatLng and LatLngAltitude points are movable, so they can be moved in any direction using the move method.

use Powlam\Coordinates\Enums\Heading;
use Powlam\Coordinates\Enums\Units;
use Powlam\Coordinates\LatLngAltitude;

$latLngAlt = (new LatLngAltitude(1.23, 4.56, 0.0))
    ->move(Heading::NORTH, 10.0)
    ->move(Heading::SOUTH, 1.0)
    ->move(Heading::EAST, 20.0)
    ->move(Heading::WEST, 5.0)
    ->move(Heading::UP, 100.0, Units::METERS)
    ->move(Heading::DOWN, 30.0, Units::METERS);

// at this point $latLngAlt is at (10.23, 19.56, 70.0)

Note: Latitude movements stop when reaching the North or South Pole.

Moving areas

The LatLngBounds rectangles are also movable; the entire area is moved at once.

When moving a LatLngBounds rectangle towards east or west using meters or kilometers, the conversion between distance and degrees depends on the latitude. The corresponding degrees will be calculated based on the midpoint latitude of the area.

Interaction between bounds

LatLngBounds classes can interact with each other:

use Powlam\Coordinates\LatLng;
use Powlam\Coordinates\LatLngBounds;

$bounds = new LatLngBounds(new LatLng(1, 1), new LatLng(10, 10));
// $bounds refers to (1, 1|10, 10)

$bounds->intersects(new LatLngBounds(new LatLng(5, 5), new LatLng(15, 15))); // returns true
$bounds->intersects(new LatLngBounds(new LatLng(15, 15), new LatLng(20, 20))); // returns false

$union = $bounds->union(new LatLngBounds(new LatLng(5, 6), new LatLng(15, 16)));
// $union refers to (1, 1|15, 16)

Also a LatLngBounds can interact with a LatLng point:

use Powlam\Coordinates\LatLng;
use Powlam\Coordinates\LatLngBounds;

$bounds = new LatLngBounds(new LatLng(1, 1), new LatLng(10, 10));
// $bounds refers to (1, 1|10, 10)

$bounds->contains(new LatLng(5, 5)); // returns true
$bounds->contains(new LatLng(-5, 5)); // returns false

$bounds->extend(new LatLng(15, 16));
// at this point $bounds has been extended to (1, 1|15, 16)

Unions and extensions are always done in the closest way possible. When talking about the longitude, usually there are 2 ways of making the join: towards west or towards east. This library selects the closest one or, in case of a tie, towards east.

Places

There is a list of geographical points, lines and areas into the Place enum.

Through the get() method you can retrieve the underlying LatLng, LatLngAltitude or LatLngBounds object that represents it.

Each of them can be used as any other LatLng, LatLngAltitude or LatLngBounds object.

use Powlam\Coordinates\Enums\Place;

$northernHemisphere = Place::NORTHERN_HEMISPHERE->get();

$northernHemisphere->contains(new LatLng(5, 5)); // returns true

Utils

Latitude and Longitude

These classes facilitate converting between degrees and meters or kilometers in both directions.

This is especially useful in the case of longitudes, because the ratio changes depending on the latitude.

use Powlam\Coordinates\Utils\Latitude;
use Powlam\Coordinates\Utils\Longitude;

Latitude::metersPerDegree(); // returns 111319.9
Latitude::degreesFromKilometers(Latitude::KILOMETERS_PER_DEGREE); // returns 1.0

Longitude::metersPerDegree(latitudeDegrees: 0.0); // returns 111319.9
Longitude::metersPerDegree(latitudeDegrees: -45.0); // returns 78715.056171
Longitude::metersPerDegree(latitudeDegrees: -45.0); // returns 78715.056171
Longitude::degreesFromMeters(Longitude::METERS_PER_DEGREE_AT_EQUATOR, latitudeDegrees: 0.0); // returns 1.0
Longitude::degreesFromMeters(Longitude::METERS_PER_DEGREE_AT_EQUATOR, latitudeDegrees: 90.0); // returns INF
Longitude::kilometersFromDegrees(1.0, latitudeDegrees: -45.0); // returns 78.715056

FloatCompare

Testing floating point values for equality is problematic, due to the way that they are represented internally. To test floating point values for equality, an upper bound on the relative error due to rounding is used. This delta is the smallest acceptable difference in calculations.

The methods implemented into the FloatCompare class allow comparing float numbers due to an internal delta value.

use Powlam\Coordinates\Utils\FloatCompare;

FloatCompare::equals(1.0, 1.000001); // returns true

FloatCompare::equalOrLessThan(1.0, 0.9999999) // returns true
FloatCompare::equalOrLessThan(1.0, 2.0) // returns true

📚 The full API of this library is available in this file.

Coordinates for PHP was created by Paul Albandoz under the MIT license.
