charts2018

Charts is a multi-library chart package to create interactive charts using laravel.

Installation
- Video Tutorial
Default Settings
Example Usage
Create Charts
Multi Datasets Chart
Database Charts
Realtime Charts
Math Functions Charts
Charts Functions
Available Chart Settings
Chart Examples
Extend your way

Installation

Video Tutorial

To install charts use composer

Download

composer require github2018/charts

//composer require hilioski/charts

Add service provider & alias

Add the following service provider to the array in: config/app.php

ConsoleTVs\Charts\ChartsServiceProvider::class,

Add the following alias to the array in: config/app.php

'Charts' => ConsoleTVs\Charts\Charts::class,

Publish the assets

php artisan vendor:publish --tag=charts_config
php artisan vendor:publish --tag=charts_assets --force

Default Settings

The file in: config/charts.php contains an array of settings, you can find the default settings in there.

Example Usage

Example Controller:

<?php

namespace App\Http\Controllers;

use Illuminate\Http\Request;

use App\Http\Requests;
use Charts;

class TestController extends Controller
{

      public function index()
    {
        $chart = Charts::multi('bar', 'material')
            // Setup the chart settings
            ->title("My Cool Chart")
            // A dimension of 0 means it will take 100% of the space
            ->dimensions(0, 400) // Width x Height
            // This defines a preset of colors already done:)
            ->template("material")
            // You could always set them manually
            // ->colors(['#2196F3', '#F44336', '#FFC107'])
            // Setup the diferent datasets (this is a multi chart)
            ->dataset('Element 1', [5,20,100])
            ->dataset('Element 2', [15,30,80])
            ->dataset('Element 3', [25,10,40])
            // Setup what the values mean
            ->labels(['One', 'Two', 'Three']);

        return view('test', ['chart' => $chart]);
    }


    public function index()
    {
		$chart = Charts::create('line', 'highcharts')
			->setTitle('My nice chart')
			->setLabels(['First', 'Second', 'Third'])
			->setValues([5,10,20])
			->setDimensions(1000,500)
			->setResponsive(false);
		return view('test', ['chart' => $chart]);
    }
}

Example View:

<!DOCTYPE html>
<html lang="en">
    <head>
        <meta charset="utf-8">
        <meta http-equiv="X-UA-Compatible" content="IE=edge">
        <meta name="viewport" content="width=device-width, initial-scale=1">

        <title>My Charts</title>

		{!! Charts::assets() !!}

    </head>
    <body>
        <center>
			{!! $chart->render() !!}
		</center>
    </body>
</html>

Create Charts

Create Charts	line	area	bar	pie	donut	geo	gauge	temp	percentage	progressbar
chartjs	x	x	x	x	x	-	-	-	-	-
highcharts	x	x	x	x	x	x	-	-	-	-
google	x	x	x	x	x	x	x	-	-	-
material	x	-	x	-	-	-	-	-	-	-
chartist	x	x	x	x	x	-	-	-	-	-
fusioncharts	x	x	x	x	x	-	-	-	-	-
morris	x	x	x	-	x	-	-	-	-	-
plottablejs	x	x	x	x	x	-	-	-	-	-
minimalist	x	x	x	x	x	-	-	-	-	-
canvas-gauges	-	-	-	-	-	-	x	x	-	-
justgage	-	-	-	-	-	-	x	-	x	-
progressbarjs	-	-	-	-	-	-	-	-	x	x

The first argument of the create method is the chart type, and the second is the library

Charts::create('line', 'highcharts')
	->setTitle('My nice chart')
	->setLabels(['First', 'Second', 'Third'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Multi Datasets Chart

Multi Dataset Charts	line	area	bar	pie	donut	geo	gauge	temp	percentage	progressbar
chartjs	x	x	x	-	-	-	-	-	-	-
highcharts	x	x	x	-	-	-	-	-	-	-
google	x	x	x	-	-	-	-	-	-	-
material	x	-	x	-	-	-	-	-	-	-
chartist	x	x	x	-	-	-	-	-	-	-
fusioncharts	x	x	x	-	-	-	-	-	-	-
morris	x	x	x	-	-	-	-	-	-	-
plottablejs	x	x	x	-	-	-	-	-	-	-
minimalist	x	x	x	-	-	-	-	-	-	-
canvas-gauges	-	-	-	-	-	-	-	-	-	-
justgage	-	-	-	-	-	-	-	-	-	-
progressbarjs	-	-	-	-	-	-	-	-	-	-

To create multi-dataset charts simply add the values using the setDataset() function!

Charts::multi('line', 'highcharts')
	->setColors(['#ff0000', '#00ff00', '#0000ff'])
	->setLabels(['One', 'Two', 'Three'])
	->setDataset('Test 1', [1,2,3])
	->setDataset('Test 2', [0,6,0])
	->setDataset('Test 3', [3,4,1]);

setDataset(required string $element_label, required array $values)

	Charts::multi('bar', 'minimalist')
	            ->setResponsive(false)
	            ->setDimensions(0, 500)
	            ->setColors(['#ff0000', '#00ff00', '#0000ff'])
	            ->setLabels(['One', 'Two', 'Three'])
	            ->setDataset('Test 1', [1,2,3])
	            ->setDataset('Test 2', [0,6,0])
	            ->setDataset('Test 3', [3,4,1]);

Database Charts

You can also generate database charts with simple setup!

$chart = Charts::database(User::all(), 'bar', 'highcharts');

Example data:

Note: You are required to use a specific group method before rendering the chart!

Important: To work with the GroupByYear, GroupByMonth, GroupByDay, lastByYear, lastByMonth & lastByDay you'll need the column created_at in the data rows.

The available methods are:

setData(required mixed $data)

Setup the data again.

 $chart = Charts::database(User::all(), 'bar', 'highcharts')->setData(Role::all());

setDateColumn(required string $column)

Set the column to group the data.

Default: created_at

 $chart = Charts::database(User::all(), 'bar', 'highcharts')->setDateColumn('my_date_column');

setDateFormat(required string $format)

Set the fancy date format for groupByDay() and lastByDay() function if $fancy set to true, must be called before those function.

Default: l dS M, Y
```
 $chart = Charts::database(User::all(), 'bar', 'highcharts')->setDateFormat('j F y');
```
setMonthFormat(required string $format)

Set the fancy date format for groupByMonth() and lastByMonth() function if $fancy set to true, must be called before those function.

Default: F, Y
```
 $chart = Charts::database(User::all(), 'bar', 'highcharts')->setDateFormat('F Y');
```

groupBy(required string $column)

Groups the data based on a column.

 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->groupBy('game');

//////////////////// $users = User::where(DB::raw("(DATE_FORMAT(created_at,'%Y'))"),date('Y'))

                  ->get();

          $chart = Charts::database($users, 'bar', 'highcharts')

                      ->title("Monthly new Register Users")

                      ->elementLabel("Total Users")

                      ->dimensions(1000, 500)

                      ->responsive(true)

                      ->groupByMonth(date('Y'), true);
  	    //////////////////////////////////

groupByYear(optional int $years)

Groups the data based in years.

Default: $years = 4

 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->groupByYear();

 // to display a number of years behind, pass a int parameter. For example to display the last 10 years:
 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->groupByYear(10);

groupByMonth(optional string $year, optional boolean $fancy)

Groups the data in months (if no year set, the current one will be used).

Default: $year = 7, $fancy = false

 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->groupByMonth();

 // to display a specific year, pass the parameter. For example to display the months of 2016 and display a fancy output label:
 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->groupByMonth('2016', true);

groupByDay(optional string $month, optional string $year, optional boolean $fancy)

Groups the data in days (if no year/month set, the current one will be used).

Default: $month = date('m'), $year = date('Y'), $fancy = false

 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->groupByDay();

 // to display a specific month and/or year, pass the parameters. For example to display the days of september 2016 and display a fancy output label:
 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->groupByDay('09', '2016', true);

lastByYear(optional int $number)

Alias for groupByYear() method. Does the same.

Default: $number = 4

 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->lastByYear();

 // to display a number of years behind, pass a int parameter. For example to display the last 3 years:
 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->lastByYear(3);

lastByMonth(optional int $number, optional boolean $fancy)

Display the numbers of months behind (relative to the current date).

Default: $number = 6, $fancy = false

 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->lastByMonth();

 // to display a number of months behind, pass a int parameter. For example to display the last 6 months and use a fancy output:
 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->lastByMonth(6, true);

lastByDay(optional int $number, optional boolean $fancy)

Display the numbers of days behind (relative to the current date).

Default: $number = 7, $fancy = false

 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->lastByDay();

 // to display a number of days behind, pass a int parameter. For example to display the last 14 days and use a fancy output:
 $chart = Charts::database(User::all(), 'bar', 'highcharts')
 	->setElementLabel("Total")
 	->setDimensions(1000, 500)
 	->setResponsive(false)
 	->lastByDay(14, true);

Realtime Charts

Realtime Charts	line	area	bar	pie	donut	geo	gauge	temp	percentage	progressbar
chartjs	-	-	-	-	-	-	-	-	-	-
highcharts	x	x	x	-	-	-	-	-	-	-
google	-	-	-	-	-	-	x	-	-	-
material	-	-	-	-	-	-	-	-	-	-
chartist	-	-	-	-	-	-	-	-	-	-
fusioncharts	-	-	-	-	-	-	-	-	-	-
morris	-	-	-	-	-	-	-	-	-	-
plottablejs	-	-	-	-	-	-	-	-	-	-
minimalist	-	-	-	-	-	-	-	-	-	-
canvas-gauges	-	-	-	-	-	-	x	x	-	-
justgage	-	-	-	-	-	-	x	-	x	-
progressbarjs	-	-	-	-	-	-	-	-	x	x

You can create realtime charts.

Example json:

{"value":31}

'value' can be changed to diferent index name with setValueName($string)

$chart = Charts::realtime(url('/path/to/json'), 2000, 'gauge', 'google')
            ->setValues([65, 0, 100])
            ->setLabels(['First', 'Second', 'Third'])
            ->setResponsive(false)
            ->setHeight(300)
            ->setWidth(0)
            ->setTitle("Permissions Chart")
			->setValueName('value'); //This determines the json index for the value

Note: The interval is set in ms

The available methods are:

setValueName(required string $string)

Sets the value json index.

Default: value

$chart = Charts::realtime(url('/path/to/json'), 2000, 'gauge', 'google')
			->setValues([65, 0, 100])
			->setLabels(['First', 'Second', 'Third'])
			->setResponsive(false)
			->setHeight(300)
			->setWidth(0)
			->setTitle("Permissions Chart")
			->setValueName('value'); //This determines the json index for the value

setUrl(required string $url)

Sets the url after chart object creation.

$chart = Charts::realtime(url('/path/to/json'), 2000, 'gauge', 'google')
			->setValues([65, 0, 100])
			->setLabels(['First', 'Second', 'Third'])
			->setResponsive(false)
			->setHeight(300)
			->setWidth(0)
			->setTitle("Permissions Chart")
			->setUrl(url('/new/json'));

setInterval(required int $interval)

Sets the interval after chart object creation (ms).

$chart = Charts::realtime(url('/path/to/json'), 2000, 'gauge', 'google')
			->setValues([65, 0, 100])
			->setLabels(['First', 'Second', 'Third'])
			->setResponsive(false)
			->setHeight(300)
			->setWidth(0)
			->setTitle("Permissions Chart")
			->setInterval(3000); // in ms

setMaxValues(required int $number)

Sets the max ammount of values to be seen before removing the first one.

$chart = Charts::realtime(url('/path/to/json'), 1000, 'area', 'highcharts')
			->setResponsive(false)
			->setHeight(300)
			->setWidth(0)
			->setTitle("Permissions Chart")
			->setMaxValues(10);

Math Functions Charts

You can create math function charts.

Charts::math('sin(x)', [0, 10], 0.2, 'line', 'highcharts');

The function is sin(x), the interval is [0, 10] and the x amplitude is 0.2

setFunction(required string $function)

Sets the function.

Charts::math('sin(x)', [0, 10], 0.2, 'line', 'highcharts')->setFunction('x+1');

setInterval(required array $interval)

Sets the function / chart interval.

 Charts::math('sin(x)', [0, 10], 0.2, 'line', 'highcharts')->setInterval([2, 8]);

setAmplitude(required int $amplitude)

Sets the function amplitude between x points.

 Charts::math('sin(x)', [0, 10], 0.2, 'line', 'highcharts')->setAmplitude(0.5);

calculate()

Calculates the valeus / labels for the chart.

Note: This function is called every time a modification is made in the chart function, interval or amplitude so you don't need to call it every time you change the values. It's just an auxiliary function.
```
 Charts::math('sin(x)', [0, 10], 0.2, 'line', 'highcharts')->calculate();
```

Charts Functions

create(optional string $type, optional string $library)

Returns a new chart instance, if no library is specified, the default one will be used.
```
Charts::create('line');
Charts::create('line', 'highcharts');
```
database(required mixed $object, optional string $type, optional string $library)

Returns a new database chart instance that extends the base one.
```
 Charts::database(User::all());
 Charts::create(User::all(), 'line', 'highcharts');
```
realtime(required string $url, required int $interval, optional string $type, optional string $library)

Returns a new database chart instance that extends the base one.
```
 Charts::realtime(url('/json/data'), 2000, 'gauge', 'google')
```
realtime(required string $function, required array $interval, required int $amplitude, optional string $type, optional string $library)

Returns a new math function chart instance that extends the base one.
```
 Charts::math('sin(x)', [0, 10], 0.2, 'line', 'highcharts');
```
assets(optional array $libraries)

Returns all the assets to generate the graphs.

To output only certain libraries, add an array to it with the libraries you want
```
 <?php echo Charts::assets(); ?>

 // Using blade
 {!! Charts::assets() !!}

 // Only certain libraries
 {!! Charts::assets(['google', 'chartjs']) !!}
```

libraries(optional string $type)

Returns an array of all the libraries available (can be filtered).

// Return all the libraries available
print_r(Charts::libraries());

// Return all the libraries available for the line chart
print_r(Charts::libraries('line'));

types(optional string $library)

Returns an array of all the chart types available (can be filtered).

// Return all the chart types available
print_r(Charts::types());

// Return all the chart types available for the highcharts library
print_r(Charts::libraries('highcharts'));

Available Chart Settings:

setGaugeStyle(required string $style)

Set the gauge style

Default: left

Available options: left right center
```
 Charts::create('gauge', 'google')->setGaugeStyle('right');
```
setType(required string $type)

Set the chart type after creation (Example: from line to pie).
```
Charts::create('line', 'highcharts')->setType('pie');
```
setLibrary(required string $library)

Set the chart library after creation (Example: from highcharts to google).
```
Charts::create('line', 'highcharts')->setLibrary('google');
```

setLabels(required array $labels)

The labels of the chart.

Charts::create('line', 'highcharts')->setLabels(['First', 'Second', 'Third']);

setValues(required array $values)

The values of the chart respectively.
```
Charts::create('line', 'highcharts')->setValues([10, 50, 100]);
```
setElementLabel(required string $element_label)

The element label for line / bar / geo charts.
```
Charts::create('line', 'highcharts')->setElementLabel('Total Views');
```

setTitle(required string $title)

The chart title.

Charts::create('line', 'highcharts')->setTitle('My Chart');

setColors(required array $colors)

The colors of the charts respectively.

Charts::create('line', 'highcharts')->setColors(['#ff0000', '#00ff00', '#0000ff']);

setWidth(required int $width)

The chart width if non-responsive. 0 = responsive width.
```
Charts::create('line', 'highcharts')->setWidth(1000);
```
setHeight(required int $height)

The chart height if non-responsive. 0 = responsive height.
```
Charts::create('line', 'highcharts')->setHeight(500);
```
setDimensions(required int $width, required int $height)

The chart dimensions (shortcut to set width, height with one funcion).
```
Charts::create('line', 'highcharts')->setHeight(1000, 500);
```
setResponsive(required boolean $responsive)

Set if the chart is responsive or not. If not, the chart dimensions will be used.
```
Charts::create('line', 'highcharts')->setResponsive(false);
```

settings()

Return the chart settings.

print_r(Charts::create('line', 'highcharts')->settings());

render()

Render the chat.

echo Charts::create('line', 'highcharts')->setLabels(['One', 'Two'])->setValues([10, 20])->render();

Chart Examples

Pie

Note: highcharts can't change the color of this chart. Well it can but it's complicated, so I leave it here.

Charts::create('pie', 'highcharts')
	->setTitle('My nice chart')
	->setLabels(['First', 'Second', 'Third'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Donut / Doughnut

Note: highcharts and chartist can't change the color of this chart. Well they can but it's complicated, so I leave it here.

Charts::create('donut', 'highcharts')
	->setTitle('My nice chart')
	->setLabels(['First', 'Second', 'Third'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Line

Charts::create('line', 'highcharts')
	->setTitle('My nice chart')
	->setElementLabel('My nice label')
	->setLabels(['First', 'Second', 'Third'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Area

Charts::create('area', 'highcharts')
	->setTitle('My nice chart')
	->setElementLabel('My nice label')
	->setLabels(['First', 'Second', 'Third'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Bar

Note: highcharts can't change the color of this chart. Well it can but it's complicated, so I leave it here.

Charts::create('bar', 'highcharts')
	->setTitle('My nice chart')
	->setElementLabel('My nice label')
	->setLabels(['First', 'Second', 'Third'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

ColorBar

Note: colorbar not include element label legend.

Charts::create('colorbar', 'highcharts')
	->setTitle('My nice colorful chart')
  ->setColors(['#e04f67', '#7cb5ec'])
	->setLabels(['First', 'Second'])
	->setValues([5,10])
	->setDimensions(200,200)
	->setResponsive(false);

Geo

Note: The labels must have the country codes, not the name.

Note 2: To add color to the chart, you'll need to provide an array of at least 2 colors. The first is the min and the second the max.

Charts::create('geo', 'highcharts')
	->setTitle('My nice chart')
	->setElementLabel('My nice label')
	->setLabels(['ES', 'FR', 'RU'])
	->setColors(['#C5CAE9', '#283593'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Gauge

Note: You either need 1 value or 3 following this standar: [actualValue, minValue, maxValue]

Charts::create('gauge', 'canvas-gauges')
	->setTitle('My nice chart')
	->setElementLabel('My nice label')
	->setValues([65,0,100])
	->setResponsive(false)
	->setHeight(300)
	->setWidth(0);

Temperature

Note: You either need 1 value or 3 following this standar: [actualValue, minValue, maxValue]

Charts::create('temp', 'canvas-gauges')
	->setTitle('My nice chart')
	->setElementLabel('My nice label')
	->setValues([65,0,100])
	->setResponsive(false)
	->setHeight(300)
	->setWidth(0);

Percentage

Note: You either need 1 value or 3 following this standar: [actualValue, minValue, maxValue]

Charts::create('percentage', 'justgage')
	->setTitle('My nice chart')
	->setElementLabel('My nice label')
	->setValues([65,0,100])
	->setResponsive(false)
	->setHeight(300)
	->setWidth(0);

Progressbar

Note: You either need 1 value or 3 following this standar: [actualValue, minValue, maxValue]

Charts::create('progressbar', 'progressbarjs')
	->setValues([65,0,100])
	->setResponsive(false)
	->setHeight(50)
	->setWidth(0);

Extend your way!

You can create your own Charts by forking this repository. The src/Templates folder contains all the current charts, but you can add yours like this:

Create a new file

Create a new file, the syntax is: library.type.php

if your chart library is called: mylib and your template is for the line chart: line Then you create a file like this: mylib.line.php

To call it later, just use:

$chart = Charts::create('line', 'mylib');

You will need to add the CSS / JS to the includes.php file found in the /src folder.

You have plenty of examples to see how to put the data so just take a closer look at all the included templates before doing yours!

github2018 / charts

Maintainers

Details

README

charts2018

Charts is a multi-library chart package to create interactive charts using laravel.

Table Of Contents

Installation

Video Tutorial

Download

Add service provider & alias

Publish the assets

Default Settings

Example Usage

Create Charts

Multi Datasets Chart

Database Charts

Realtime Charts

Math Functions Charts

Charts Functions

Available Chart Settings:

Chart Examples

Pie

Donut / Doughnut

Line

Area

Bar

ColorBar

Geo

Gauge

Temperature

Percentage

Progressbar

Extend your way!

Create a new file
