eca-devtools/docsystem

In-app documentation and tracking system per URL/page for development environments.

v1.1.0 2026-03-28 10:06 UTC

Requires

• php: ^8.3
• illuminate/database: ^11.0|^12.0|^13.0
• illuminate/filesystem: ^11.0|^12.0|^13.0
• illuminate/support: ^11.0|^12.0|^13.0
• livewire/livewire: ^3.0|^4.0

MIT

• ECADevTools

README

Development-only in-app documentation and activity tracking system, per URL/page.

Features

Feature	Details
📄 Page docs	Each URL gets its own doc record, auto-detected
🔖 Versioning	Multiple versions per page (title, description, author)
📅 Timeline	Full activity log with metadata
📝 Notes	Types: avance, pregunta, error, nota
📎 Files	Upload files with version history
🔍 Diff viewer	Line-by-line diff for text files (LCS algorithm)
🛡️ Dev only	Auto-disabled in production environment
🧹 Purge	One-command full cleanup

Requirements

• PHP 8.3+
• Laravel 11 / 12 / 13
• Livewire v3 or v4
• Tailwind CSS (already in your project)

Installation

1. Require the package

composer require eca-devtools/docsystem

2. Publish and run migrations

php artisan vendor:publish --tag=docsystem-migrations
php artisan migrate

3. (Optional) Publish config

php artisan vendor:publish --tag=docsystem-config

The floating button is injected automatically into every HTML response for authenticated users in non-production environments — no layout changes needed.

4. Add Tailwind source (required for compiled CSS setups)

If your project uses Tailwind with a compiled build (Vite / webpack), the panel's utility classes won't be generated unless you tell Tailwind to scan the package views. Add this line to your CSS entry file (e.g. resources/css/app.css):

@source '../../vendor/eca-devtools/docsystem/resources/views/**/*.blade.php';

Then rebuild your assets:

npm run build
# or, during development:
npm run dev

If you skip this step the button will be injected into the HTML but will appear invisible due to missing styles.

Usage

1. Visit any page while authenticated.
2. A floating indigo button appears in the bottom-right corner.
3. Click it to open the panel.

Tabs

Tab	Actions
Documentation	Create / edit version records with title, version number & description
Timeline	Read-only activity log ordered by newest first
Notes	Add typed notes (avance, pregunta, error, nota)
Files	Upload files, add new versions, download, or compare (diff) text files

File diff

For text-based files (.txt, .md, .json, .php, .js, etc.) a Diff button appears between versions. It renders a side-by-side line-level comparison using a built-in LCS algorithm — no external library required.

Configuration (config/docsystem.php)

return [
    'enabled'          => env('DOCSYSTEM_ENABLED', true),
    'storage_path'     => env('DOCSYSTEM_STORAGE_PATH', 'doc-system'),
    'max_file_size'    => env('DOCSYSTEM_MAX_FILE_SIZE', 10240), // KB
    'text_extensions'  => ['txt','md','json','php','js','ts', ...],
    'note_types'       => ['avance','pregunta','error','nota'],
    'event_types'      => ['created','updated','note_added','file_uploaded',
                           'file_updated','file_deleted'],
];

Commands

Purge (cleanup)

php artisan docsystem:purge

This command:

• Only runs in local / non-production environments
• Asks for explicit confirmation
• Drops all package database tables (doc_pages, doc_versions, doc_events, doc_notes, doc_files, doc_file_versions)
• Deletes all files from storage/app/public/doc-system

Database tables

Table	Description
doc_pages	One record per unique URL path
doc_versions	Version history per page
doc_events	Timeline / activity log
doc_notes	Typed notes per page
doc_files	Logical file entities (groups versions)
doc_file_versions	Individual uploaded file versions

Screenshots (placeholders)

Floating button

Documentation tab

Timeline tab

Notes tab

Files + Diff tab

Production safety

The package automatically refuses to boot if:

app()->environment('production') === true

No routes, no Livewire components, no commands will be registered in production. Zero overhead.

Uninstall

# 1. Run purge to clean database tables and files
php artisan docsystem:purge

# 2. Remove the package
composer remove eca-devtools/docsystem

# 3. Remove the component tag from your layout
# (delete the <livewire:docsystem-panel /> line)

# 4. (Optional) Remove published config
rm config/docsystem.php

License

MIT
