alrajhi/payment-gateway

Clean Laravel package for Al Rajhi Bank Payment Gateway - Bank Hosted Integration Only

v1.0.9 2026-04-07 13:36 UTC

Requires

• php: ^8.1
• guzzlehttp/guzzle: ^7.2
• laravel/framework: ^10.0|^11.0|^12.0

MIT

• Yacoub Al-haidari

• payment
• gateway
• laravel
• alrajhi
• bank-hosted
• api-only

README

AlRajhi Payment Gateway (Laravel Package)

Lightweight Laravel package for Al Rajhi Bank Payment Gateway integration.

What this package provides

• Bank Hosted payment initiation
• Faster Checkout support
• Iframe support
• Apple Pay (Bank Hosted path)
• Webhook processing service
• BIN check helper
• Unified response normalization and exception shape
• UDF1..UDF10 forwarding + validation
• Clean internal architecture (orchestrators + dedicated services)

Installation

composer require alrajhi/payment-gateway
php artisan vendor:publish --tag=alrajhi-config

Configuration

Set these values in your .env:

ALRAJHI_BASE_URL=https://securepayments.alrajhibank.com.sa
ALRAJHI_ENVIRONMENT=sandbox
ALRAJHI_TRANPORTAL_ID=your_tranportal_id
ALRAJHI_TRANPORTAL_PASSWORD=your_password
ALRAJHI_RESOURCE_KEY=your_resource_key

# Compatibility toggles for trandata encryption/decryption
ALRAJHI_URL_ENCODE_BEFORE_ENCRYPT=false
ALRAJHI_URL_DECODE_AFTER_DECRYPT=false
ALRAJHI_RETRY_RAW_TRANDATA_ON_INVALID=true

ALRAJHI_RESPONSE_URL=${APP_URL}/api/payment/success
ALRAJHI_ERROR_URL=${APP_URL}/api/payment/failed
ALRAJHI_WEBHOOK_SECRET=your_webhook_secret

ALRAJHI_STRICT_RESPONSE_MODE=false
ALRAJHI_ACCEPT_QUERY_RESPONSE=true
ALRAJHI_ACCEPT_DIRECT_CALLBACK_FIELDS=true
ALRAJHI_SUCCESS_STATUSES=1,success,approved,captured,processing,voided

ALRAJHI_PREFER_CATALOG_MESSAGE=true
ALRAJHI_INCLUDE_OFFICIAL_MESSAGE=true

ALRAJHI_UDF_AUTO_FILL_DEFAULTS=false
ALRAJHI_CAPTURE_AUTO_SET_UDF7_R=true

Quick start

use AlRajhi\PaymentGateway\Facades\AlRajhiPayment;

Route::post('/test-payment', function (Request $request) {
    $trackId = 'TRK-' . now()->format('YmdHis') . '-' . random_int(1000, 9999);

    try {
        $payment = AlRajhiPayment::bankHosted()->initiate([
            'id' => env('ALRAJHI_TRANPORTAL_ID'),
            'password' => env('ALRAJHI_TRANPORTAL_PASSWORD'),
            'amount' => '400.00',
            'action' => '1',
            'currencyCode' => '682',
            'trackId' => $trackId,
            'responseURL' => env('ALRAJHI_RESPONSE_URL'),
            'errorURL' => env('ALRAJHI_ERROR_URL'),
            'response_url' => env('ALRAJHI_RESPONSE_URL'),
            'error_url' => env('ALRAJHI_ERROR_URL'),
            'customerIp' => $request->ip(),
        ]);

        return response()->json([
            'success' => true,
            'payment' => $payment,
        ]);
    } catch (\Throwable $e) {
        return response()->json([
            'success' => false,
            'error' => $e->getMessage(),
            'exception' => get_class($e),
        ], 500);
    }
});

Test Success response shape:

[
         "success": true,
        "payment_id": "60000260000768000",
        "payment_url": "https://securepayments.alrajhibank.com.sa/pg/paymentpage.htm",
        "redirect_url": "https://securepayments.alrajhibank.com.sa/pg/paymentpage.htm?PaymentID=60000260000768",
        "track_id": "TRK-20260402093943-8348"
]

Live Success response shape:

[
        "success": true,
        "payment_id": "700202609733477641",
        "payment_url": "https://digitalpayments.neoleap.com.sa/pg/paymentpage.htm",
        "redirect_url": "https://digitalpayments.neoleap.com.sa/pg/paymentpage.htm?PaymentID=700202609733477641",
        "track_id": "TRK-20260407130233-4761"
]

Flow Charts

1) Payment flow (Bank Hosted)

flowchart TD
    A[Merchant Backend: initiate] --> B[Prepare payload\ncallbacks + customer_ip + UDF defaults]
    B --> C[Encrypt trandata\nAES-256-CBC + IV]
    C --> D[Send token request to ARB\nwith X-FORWARDED-FOR]
    D --> E{Initial status == success?}
    E -- No --> F[Throw PaymentGatewayException]
    E -- Yes --> G[Receive paymentId:paymentUrl]
    G --> H[Build redirect_url with PaymentID]
    H --> I[Customer pays on ARB page]
    I --> J[Merchant callback receives final response]
    J --> K{Has trandata?}
    K -- Yes --> L[Decrypt + normalize result]
    K -- No --> M[Fallback parse top-level fields]
    L --> N[Use helpers: isSuccess/isCaptured/...]
    M --> N

Loading

2) Webhook flow

flowchart TD
    A[ARB sends webhook] --> B[WebhookService.process]
    B --> C[Verify signature\nif secret configured]
    C --> D[Resolve payload/result nodes]
    D --> E{Status is success or pending?}
    E -- Yes --> F[Map normalized transaction data]
    F --> G[Run success callback]
    E -- No --> H[Map failure payload]
    H --> I[Run failure callback]
    G --> J[Return status=1 ack]
    I --> J

Loading

Response handling behavior

• First priority is trandata (decrypt and parse it).
• If trandata is missing, fallback to top-level fields (ErrorText, Error, etc.).
• Accepts JSON arrays/objects and query-string-like payloads.
• Key names are normalized (paymentId/paymentid, errorText/errortext, trackId/trackid).

UDF policy

• Supports udf1 to udf10 in request and normalized response.
• Each UDF must be scalar and max length 255.
• Auto defaults for missing udf1..udf5 (when enabled):
  • udf1 = order:{order_id|track_id}
  • udf2 = customer:{customer_id}
  • udf3 = channel:{channel} (default web)
  • udf4 = source:{source} (default bank_hosted, iframe for iframe flow)
  • udf5 = ref:{reference_type} (default TrackID)
• Capture compliance:
  • For action=5, auto-set udf7=R (non-saved-card capture) when missing and enabled.
  • For action=5, udf10 (if provided) must be PARTIALCAPTURE or FINALCAPTURE.

Callback vs Webhook (recommended pattern)

• Always use webhook as the single source of truth for order/payment updates.
• Use paymentCallback for UX only (redirect page/message), not for final state changes.

Handling callback result (UX only)

// webhook endpoint for testing callback handling
Route::post('/payment/success', function (Request $request) {
    $result = AlRajhiPayment::bankHosted()->handleResponse($request->all());
    $GetResult = AlRajhiPayment::bankHosted()->handleResponseData($result);

    // منطق تحديد الحالة الموحدة
    $statusFinal = $GetResult['status_final'] ?? 'unknown';
    $bankStatus  = $GetResult['bank_status'] ?? null;

    $paymentStatus = match ($statusFinal) {
        'success'   => 'success',
        'failed'    => 'failed',
        'pending'   => 'pending',
        'voided'    => 'voided',
        'cancelled' => 'cancelled',
        default     => $bankStatus ?? 'unknown',
    };

    // Payment::update([...], ['status' => $paymentStatus]);
    // Order::update([...], ['status' => ...]);

    return response()->json(array_merge($GetResult, [
        'payment_status' => $paymentStatus,
    ]));

});
Route::post('/payment/failed', function (Request $request) {

    Log::info('Payment failed callback received', $request->all());
});



// Recommended in callback: return message/view only
// Do NOT finalize order/payment status here.

Update order and payment records (Webhook-driven)

Use your own models, and update states only inside webhook handlers.

#As Test I made it in the Route.php
use AlRajhi\PaymentGateway\Facades\AlRajhiPayment;
Route::post('/webhook', function (Request $request) {
    $payload = $request->all();

    // تسجيل البيانات للمتابعة
    Log::info('AlRajhi Webhook received', $payload);

    // استخراج أهم الحقول
    $result    = $payload['result'][0] ?? [];
    $payLoad   = $payload['payLoad'][0] ?? [];
    $type      = $payload['type'] ?? null;
    $trackId   = $payLoad['trackId'] ?? null;
    $paymentId = $payLoad['paymentId'] ?? null;
    $status    = $result['status'] ?? ($result['error'] ?? null);

    // Payment::where('track_id', $trackId)->update([...]);
    // Order::where('payment_id', $paymentId)->update([...]);

    return response()->json([['status' => '1']]);
});

Webhook endpoint (primary)

The package registers:

POST /alrajhi/webhook

Implementation example is already provided in:

• Update order and payment records (Webhook-driven)

Callback endpoint (secondary / UX only)

Use callback endpoint to show user-facing result page or redirect logic only. Do not make final order/payment updates here.

BIN check

$binData = AlRajhiPayment::binCheck('515735');

Troubleshooting IPAY0100013 (Invalid transaction data)

When the gateway returns IPAY0100013, validate these items exactly:

• Endpoint URL must be your assigned gateway host (many merchants currently use https://securepayments.neoleap.com.sa).
• Required transaction fields must be present with exact meaning:
  • id (tranportal id)
  • password (tranportal password)
  • action=1
  • currencyCode=682
  • amt with 2 decimals (example 12.00)
  • trackId unique value
  • responseURL and errorURL valid public HTTPS URLs
• Resource key must match the same environment/credentials pair.
• If you changed .env, run:

php artisan optimize:clear

This package now retries once automatically without URL-encoding trandata when the gateway returns IPAY0100013.
