2chain/pimcore-messenger-dashboard

Pimcore admin dashboard for Symfony Messenger queues, with audit stats, delete/requeue, and permission gating.

v0.0.1 2026-05-15 12:19 UTC

Requires

• php: ^8.2
• doctrine/migrations: ^3.7
• doctrine/orm: ^2.17 || ^3.0
• pimcore/pimcore: ^11.0 || ^12.0
• symfony/messenger: ^6.4 || ^7.0

Requires (Dev)

• dama/doctrine-test-bundle: ^8.0
• friendsofphp/php-cs-fixer: ^3.50
• phpstan/phpstan: ^1.10
• phpstan/phpstan-symfony: ^1.3
• phpunit/phpunit: ^10.5 || ^12.0

GPL-3.0-or-later

README

A Pimcore admin dashboard for Symfony Messenger queues. View pending and failed messages across every configured transport, inspect message bodies, delete single or in bulk, re-queue failed messages, and watch handler throughput over time — all from a permission-gated tab inside Pimcore's classic admin UI.

Package	2chain/pimcore-messenger-dashboard
PHP namespace	TwoChain\PimcoreMessengerDashboardBundle\
Bundle class	TwoChain\PimcoreMessengerDashboardBundle\PimcoreMessengerDashboardBundle
Pimcore	^11.0 || ^12.0
Symfony Messenger	^6.4 || ^7.0
License	GPL-3.0-or-later

Features

• Transport sidebar lists every transport configured under framework.messenger.transports, with a live pending count and capability icons. Auto-refreshes every 10 seconds (configurable).
• Message grid per transport with checkbox selection, inline body preview, hover-tooltip showing the full body, and an info icon that opens a modal with all fields and a JSON-pretty-printed body.
• Bulk operations: delete selected, delete all in transport, purge.
• Per-transport search: substring search across message body and class with SQL LIKE-style wildcards (%, _). See Searching messages.
• Failed transport view: same grid plus per-row and bulk Requeue.
• Statistics: handled vs failed counts per transport over the last 1h / 12h / 24h, sourced from an opt-out audit table written by a Messenger event subscriber.
• Permissions: two installable user permissions (view + edit). Admins bypass.
• Transport-agnostic: doesn't assume a specific table name, queue name, or transport type. Reads everything through Symfony's transport API.

Supported transports

The dashboard wraps every Symfony Messenger transport through a small adapter layer that advertises a capability set. The UI hides or disables controls the underlying transport can't support, so the same dashboard works against any mix of transport types.

Listing is the gate for every interactive feature. If a transport can't enumerate its messages (canList = false), the dashboard treats it as fully read-only: the sidebar shows (unsupported) instead of a count, the detail panel renders only the "this transport does not support listing messages" notice (no stats bar, no action buttons), and the Statistics table groups the transport at the bottom with a not supported cell. The underlying transport API may technically expose delete or purge primitives, but operating on messages you can't see is unsafe and confusing — the UI hides those controls deliberately.

The audit subsystem (messenger_dashboard_stats) still records handled / failed events for unsupported transports — those rows just don't surface in the per-transport stats view.

DSN scheme	Symfony package	Listed in dashboard	Count	List / inspect	Delete single	Bulk delete	Purge	Requeue (failed)
doctrine://	symfony/doctrine-messenger	✓ supported	✓	✓	✓	✓	✓	✓
redis:// / rediss://	symfony/redis-messenger	✓ supported	✓	✓ via XRANGE [1]	✓ via XDEL	—	✓ via XTRIM	✓
in-memory://	core	✓ supported	✓	✓	✓	✓	✓	✓
Any other receiver implementing ListableReceiverInterface	—	✓ supported	✓	✓	✓	—	—	—
amqp:// / amqps://	symfony/amqp-messenger	✗ unsupported [4]	✓	—	—	—	—	—
beanstalkd://	symfony/beanstalkd-messenger	✗ unsupported [2]	✓	—	—	—	—	—
sqs:// / https://	symfony/amazon-sqs-messenger	✗ unsupported [3]	✓	—	—	—	—	—
sync://	core	—	n/a (always 0)	—	—	—	—	—
Any other receiver implementing only MessageCountAwareInterface	—	✗ unsupported	✓	—	—	—	—	—
Anything else	—	✗ unsupported	0	—	—	—	—	—

^[1] Symfony's Redis bridge doesn't implement ListableReceiverInterface, but Redis Streams natively support read-only enumeration via the XRANGE command. The adapter reaches the underlying Redis client via reflection and calls XRANGE directly — read-only, no consumer-state mutation, no worker races. Caveat: XRANGE returns every entry currently in the stream; Symfony's transport XACKs handled messages but doesn't immediately XDEL them, so the listed entries may include already-handled messages. The transport's own getMessageCount() (shown in the sidebar) remains authoritative for "currently pending".

^[2] Beanstalkd's wire protocol has no enumeration command. peek-ready returns only the next single job in each state; full listing would require reserve → release loops that briefly hide jobs from workers (racy). Count is available; per-job operations are not.

^[3] Amazon SQS has no native peek-without-consume. ReceiveMessage with VisibilityTimeout=0 is technically possible but produces inconsistent listings (other workers receive the same messages between refreshes). Count is available via ApproximateNumberOfMessages; per-message operations are not.

^[4] AMQP brokers don't support non-destructive message enumeration in the wire protocol. RabbitMQ's HTTP Management API does (separate plugin + credentials), but the dashboard doesn't currently integrate with it.

Detection is FQCN-based. The bundle has zero hard dependencies on the optional bridges — symfony/redis-messenger etc. don't need to be in your project for the bundle to compose / boot. When a bridge isn't installed, its FQCN simply never matches.

Transports whose backend is unreachable (e.g. AMQP broker offline, SQS network error) degrade to count: unavailable in the sidebar — they don't crash the dashboard.

Not supported as DSN schemes: failover:// and roundrobin:// are sometimes referenced in older docs but are not actually Symfony Messenger transport schemes (Symfony composes multiple transports via the routing config, not via a wrapping DSN). The dashboard treats each underlying transport as its own entry, which is the correct mental model.

Third-party transports (e.g. Enqueue's Kafka or Google Pub/Sub bridges via sroze/messenger-enqueue-transport) work via the generic fallback: full features if the receiver implements ListableReceiverInterface, count-only if it implements just MessageCountAwareInterface.

Requirements

• PHP 8.2+
• Pimcore 11.x or 12.x with the Classic Admin UI bundle enabled
• Doctrine ORM 2.17+ or 3.x (Pimcore 12 ships ORM 3)
• MariaDB 10.11+ or MySQL 8.0+ if you use the audit subsystem

The bundle auto-configures Doctrine ORM mapping for its own audit entity, so you don't need ORM enabled in your project for anything else.

Installation

composer require 2chain/pimcore-messenger-dashboard

Pimcore's bundle auto-loader picks up the pimcore-bundle composer type. If your project has bundle auto-loading disabled, add it manually to config/bundles.php:

return [
    // ... your existing bundles
    \PimcoreMessengerDashboardBundle::class => ['all' => true],
];

Run the install command (registers the permissions, applies the audit table migration):

bin/console pimcore:bundle:install PimcoreMessengerDashboardBundle
bin/console doctrine:migrations:migrate --no-interaction
bin/console assets:install public --symlink --relative

Grant access through Settings → Users & Roles. Two new checkboxes appear under the "Messenger Dashboard" group:

• messenger_dashboard_view — see the dashboard
• messenger_dashboard_edit — delete, requeue, purge (implies view)

Pimcore admins (User::isAdmin() === true) bypass both.

Reload the admin UI. Tools → Messenger Dashboard opens the tab.

Configuration

Drop a twochain_messenger_dashboard.yaml into config/packages/ to override any default:

twochain_messenger_dashboard:
    stats:
        enabled: true            # set false to skip the audit subscriber entirely
        retention_days: 30       # how long to keep rows in messenger_dashboard_stats
    failed_transport:
        auto_configure: true     # prepend a default `pimcore_failed` Doctrine transport
                                 # if framework.messenger.failure_transport isn't already set
    ui:
        polling_interval_ms: 10000   # sidebar refresh interval; min 1000

stats.enabled (bool, default true)

When true, the bundle registers MessengerAuditSubscriber against Symfony's worker events and writes one row per handled or finally-failed message to messenger_dashboard_stats. This populates the Statistics panel and the per-transport "Last processed" timestamp.

When false, the subscriber short-circuits in getSubscribedEvents() — zero runtime cost. The Statistics panel hides itself with a hint.

stats.retention_days (int ≥ 1, default 30)

Rows older than this are deleted by bin/console twochain:messenger-dashboard:stats:prune. The command takes an optional --retention-days=N override and a --dry-run flag. Schedule it via crontab (the bundle does not add a cron entry itself):

0 3 * * * /var/www/html/bin/console twochain:messenger-dashboard:stats:prune

failed_transport.auto_configure (bool, default true)

If true and your framework.messenger.failure_transport is unset, the bundle prepends a default failed transport:

framework:
    messenger:
        failure_transport: pimcore_failed
        transports:
            pimcore_failed: 'doctrine://default?queue_name=pimcore_failed'

If your project already sets failure_transport, this is a no-op. Set auto_configure: false to disable the prepend entirely.

ui.polling_interval_ms (int ≥ 1000, default 10000)

How often the sidebar re-queries the transports endpoint. Polling pauses while the user is interacting with a grid (no flicker mid-selection).

Searching messages

Every listable transport detail view (plus the Failed view) has a search field above the grid. The query is matched against:

• the fully qualified message class (e.g. App\Message\ImportProduct), and
• the body preview (the JSON-serialized public properties for non-\Stringable messages, or the __toString() value otherwise).

The match uses SQL LIKE semantics: substring by default, with % and _ as wildcards. To match a literal % or _, prefix it with a backslash (\%, \_). The search field debounces 300 ms; press Enter to apply immediately, Esc or the clear-trigger to reset.

Scope is per transport. Search box on the per-transport detail view filters that transport only; the box on the Failed view filters the failure store and combines with the class filter.

Backend behavior depends on the underlying transport:

• Doctrine: parameterized LIKE … ESCAPE '\\' against the messenger table. Cheap; works at any backlog size.
• In-memory and other listable transports: same wildcards, applied in PHP via a regex. Caps at 5000 envelopes pulled per request — beyond that, search is best-effort.
• AMQP, Beanstalkd, SQS: not searchable (listing isn't supported on these brokers).
• Redis: the search field is shown for UI consistency but ignored; results come back unfiltered.

A query longer than 1024 characters is rejected with a query_too_long error.

CLI commands

Command	Purpose
twochain:messenger-dashboard:stats:prune [--retention-days=N] [--dry-run]	Delete audit rows older than the retention window.
twochain:messenger-dashboard:debug:transports	List every transport with type, capability matrix, and live count. Useful for verifying configuration outside the UI.

Translations

Translations live in Resources/translations/admin.<locale>.yaml and are auto-discovered by Symfony's translator. Pimcore's admin UI reads from the same catalogue.

The bundle ships English (en) and German (de). To add a new locale, drop a new YAML file next to the existing ones — no code changes required:

# Resources/translations/admin.fr.yaml
messenger_dashboard: Tableau de bord Messenger
messenger_dashboard_transports: Transports
# ... etc

Operator overrides through Settings → Translations → Admin Translations take precedence over the bundle's YAML defaults via Pimcore's translation catalogue merge — bundle upgrades won't clobber custom translations.

Uninstall

bin/console pimcore:bundle:uninstall PimcoreMessengerDashboardBundle
composer remove 2chain/pimcore-messenger-dashboard

The uninstall step removes the user permissions. The audit table (messenger_dashboard_stats) is left in place — drop it manually with bin/console doctrine:migrations:migrate prev (or directly via DROP TABLE messenger_dashboard_stats) if you want it gone.

License

This bundle is licensed under the GNU General Public License v3.0 or later. See LICENSE.md for the full license text.
