README

A PHP extension that brings GPU rendering, audio, video recording, streaming, and input handling to PHP. Foundation layer for the PHPolygon game engine.

Features

Multi-Backend GPU Rendering — OpenGL 4.1, Vulkan (MoltenVK), Metal
2D Batch Renderer — Rects, circles, lines, sprites, text (z-sorted, up to 4096 items)
3D Pipeline — Meshes, shaders, pipelines, textures, uniform/storage buffers
Shader Toolchain — GLSL to SPIR-V compilation, reflection, cross-compilation
Audio — Playback via miniaudio (MP3, WAV, FLAC)
Video Recording — H.264 encoding via FFmpeg (with VideoToolbox HW acceleration)
Network Streaming — RTMP and SRT via FFmpeg
Input — Keyboard, mouse, and gamepad support via GLFW
Headless Mode — Offscreen rendering for tests and visual regression testing
Plugin System — Extensible output/input/filter plugins
Cross-Platform — macOS, Linux, Windows

Requirements

PHP >= 8.4

All native libraries are optional — the extension compiles and runs without them, features are simply unavailable at runtime:

Library	Feature	Build Flag
GLFW 3.4	Windowing, input, gamepad	`--with-glfw`
glslang	GLSL to SPIR-V compilation	`--with-glslang`
SPIRV-Cross	Shader reflection & transpilation	`--with-spirv-cross`
Vulkan SDK	Vulkan backend	`--with-vulkan`
FFmpeg	Video recording & streaming	`--with-ffmpeg`
Metal (macOS framework)	Metal backend	`--with-metal`

Installation

Via PIE (PHP Installer for Extensions)

pie install phpolygon/php-vio

Pre-built Binaries

Download platform-specific binaries from the Releases page. Available for:

Linux x86_64 / ARM64
macOS x86_64 (Intel) / ARM64 (Apple Silicon)
Windows x64

From Source (macOS)

brew install glfw glslang spirv-cross ffmpeg

phpize
./configure --enable-vio --with-glfw --with-glslang --with-spirv-cross \
  --with-vulkan --with-ffmpeg --with-metal
make -j$(sysctl -n hw.ncpu)
sudo make install

From Source (Linux)

# Ubuntu/Debian
sudo apt install php-dev libglfw3-dev glslang-dev libvulkan-dev \
  libavcodec-dev libavformat-dev libavutil-dev libswscale-dev \
  spirv-cross libspirv-cross-c-shared-dev

phpize
./configure --enable-vio --with-glfw --with-glslang --with-spirv-cross \
  --with-vulkan --with-ffmpeg
make -j$(nproc)
sudo make install

Windows

On Windows, no build toolchain is needed — PHP extensions are distributed as pre-compiled DLLs. Download the matching DLL from the Releases page (match your PHP version and thread-safety mode), then:

Copy php_vio.dll into your PHP ext\ directory
Add extension=vio to your php.ini
Restart PHP / your web server

All backends use conditional compilation (#ifdef HAVE_*), so builds without certain dependencies compile fine — those features are simply unavailable at runtime.

Quick Start

<?php

// Create a window with OpenGL backend
$ctx = vio_create("opengl", [
    "width"  => 800,
    "height" => 600,
    "title"  => "Hello VIO",
]);

while (!vio_should_close($ctx)) {
    vio_begin($ctx);
    vio_clear($ctx, 0.1, 0.1, 0.1);

    // 2D drawing
    vio_rect($ctx, 50, 50, 200, 100, ["color" => 0xFF0000FF]);
    vio_circle($ctx, 400, 300, 60, ["color" => 0x00FF00FF]);
    vio_draw_2d($ctx);

    vio_end($ctx);
    vio_poll_events($ctx);
}

vio_close($ctx);
vio_destroy($ctx);

API Overview

71 functions across these categories:

Category	Functions
Context	`vio_create`, `vio_begin`, `vio_end`, `vio_clear`, `vio_close`, `vio_destroy`
Input	`vio_key_pressed`, `vio_mouse_position`, `vio_mouse_button`, `vio_on_key`
2D	`vio_rect`, `vio_circle`, `vio_line`, `vio_sprite`, `vio_text`, `vio_draw_2d`
3D	`vio_mesh`, `vio_shader`, `vio_pipeline`, `vio_bind_pipeline`, `vio_draw`
Textures	`vio_texture`, `vio_bind_texture`, `vio_texture_load_async`
Buffers	`vio_uniform_buffer`, `vio_update_buffer`
Audio	`vio_audio_load`, `vio_audio_play`, `vio_audio_pause`, `vio_audio_stop`
Recording	`vio_recorder`, `vio_recorder_capture`, `vio_recorder_stop`
Streaming	`vio_stream`, `vio_stream_push`, `vio_stream_stop`
Headless	`vio_read_pixels`, `vio_save_screenshot`, `vio_compare_images`
Shaders	`vio_shader_reflect`, shader compilation via glslang
Plugins	`vio_plugins`, `vio_plugin_info`

Full API documentation: see vio.stub.php

Backends

Backend	Status	Platforms
OpenGL 4.1	Stable	macOS, Linux, Windows
Metal	Stable	macOS only
Vulkan	Experimental	macOS (MoltenVK), Linux, Windows
Null	Stable	All (for unit testing)

Backend auto-selection: Metal (macOS) > Vulkan (Linux/Windows) > OpenGL > Null

Performance: Metal vs OpenGL

Benchmarked on Apple M2 Pro (macOS 26.4, 1280x720, VSync off). Measures draw + flush time only (excludes present/VSync wait).

Scenario	Metal (median)	OpenGL (median)	Delta
500 rects	192 us	179 us	+7%
200 rects + 200 rounded rects + 50 text	323 us	313 us	+3%
1000 rects + 100 text	301 us	374 us	-20%

Tail latency (frame time consistency):

Percentile	Metal	OpenGL
p95	306-601 us	437-754 us
p99	375-674 us	907-953 us

Metal is slightly slower on simple scenes due to command encoding overhead, but 20% faster on heavy scenes (1000+ draw calls with text). More importantly, Metal delivers 30-40% better tail latency — fewer frame time spikes and more consistent rendering.

Testing

NO_INTERACTION=1 TEST_PHP_EXECUTABLE=$(which php) \
  php run-tests.php -d extension=$PWD/modules/vio.so tests/

38 tests included, covering headless rendering, 2D/3D pipelines, shaders, audio, input, and visual regression testing.

License

MIT
