README

Laravel Loom

Architecture as data.

Loom statically analyzes a Laravel app's event-driven primitives and writes a deterministic JSON file: every event, listener, observer, job, schedule, mailable, notification, and dispatch site, each with its file path and line number. It reads source with nikic/php-parser — no app boot, no runtime tracing, no vendor/ required — so it sees what's actually in your code, not just what Laravel happened to register at boot.

composer require lucasp1337/laravel-loom --dev
php artisan loom:scan          # writes storage/loom/index.json

Usage

php artisan loom:scan               # writes storage/loom/index.json
php artisan loom:show               # prints the index
php artisan loom:show OrderPlaced   # filters by FQCN substring

Add storage/loom/index.json to .gitignore if you don't want to commit it.

What it finds

Click any item to see what gets picked up.

Events — app/Events/**, plus any class dispatched via event() / Event::dispatch()

namespace App\Events;

class OrderPlaced {}   // any class under app/Events/

// ...or any class dispatched statically, wherever it lives:
event(new OrderPlaced($order));
Event::dispatch(new OrderPlaced($order));
OrderPlaced::dispatch($order);   // counts as an event when it resolves under app/Events/

Listeners — auto-discovery, $listen arrays, Event::listen(), and subscribers

// Auto-discovered from the typed handle() argument
class SendOrderConfirmation
{
    public function handle(OrderPlaced $event): void {}
}

// $listen array on EventServiceProvider
protected $listen = [
    OrderPlaced::class => [SendOrderConfirmation::class],
];

// Event::listen() anywhere under app/
Event::listen(OrderPlaced::class, SendOrderConfirmation::class);

// Subscriber
class OrderSubscriber
{
    public function subscribe(Dispatcher $events): array
    {
        return [OrderPlaced::class => 'onOrderPlaced'];
    }
}

Closure listeners — closures registered as listeners, in their own section

Event::listen(OrderPlaced::class, function (OrderPlaced $event) {
    // captured in closure_listeners[], not listeners[]
});

Observers — Model::observe(), #[ObservedBy], and eloquent.* model events

#[ObservedBy(UserObserver::class)]
class User extends Model {}

// ...or registered imperatively
User::observe(UserObserver::class);

// ...or via an eloquent.* model event
Event::listen('eloquent.created: '.User::class, $callback);

Jobs — app/Jobs/**, plus any class dispatched via dispatch() / X::dispatch(), with queue config

class ProcessOrder implements ShouldQueue   // any class under app/Jobs/
{
    public $connection = 'redis';   // queue config read from properties
    public $queue = 'high';
    public $tries = 3;
}

// ...or any class dispatched as a job (located via PSR-4, so DDD layouts work):
dispatch(new ProcessOrder($order));
ProcessOrder::dispatch($order);
Bus::dispatch(new ProcessOrder($order));

// chain-wrapped targets resolve through the chain, and dispatch-time
// modifiers are captured as an `overrides` object on the dispatch site:
ProcessOrder::dispatch($order)->onQueue('high')->onConnection('redis');
dispatch((new ProcessOrder($order))->delay(60))->afterCommit();

Statically-resolvable dispatch-time modifiers — ->onQueue(), ->onConnection(), ->delay() (integer seconds), ->locale(), ->mailer(), ->afterCommit() — are recorded as an optional overrides object on the dispatch site. queue_config still reflects class-default declarations; overrides records what the call site changed.

Schedule — Kernel::schedule(), bootstrap/app.php, and Schedule::* chains, normalized to cron

// In Kernel::schedule(), bootstrap/app.php withSchedule(), or a Schedule:: chain under app/
$schedule->command('mail:send')->dailyAt('13:00')->weekdays();
$schedule->job(new ProcessOrder)->everyFiveMinutes();
Schedule::call(fn () => cleanup())->hourly();

Mailables — app/Mail/**, plus Mail::send() and Mail::to()->send() chains, with queue config

class OrderShipped extends Mailable implements ShouldQueue {}   // any class under app/Mail/

// ...or any class sent via Mail::
Mail::to($user)->send(new OrderShipped($order));
Mail::queue(new OrderShipped($order));

Notifications — app/Notifications/**, plus notify() / Notification::send(), with channels

class InvoicePaid extends Notification   // any class under app/Notifications/
{
    public function via($notifiable): array
    {
        return ['mail', 'database', 'slack'];   // channels read from a static via() literal
    }
}

// ...or any class sent via notify()/Notification::
$user->notify(new InvoicePaid($invoice));
Notification::send($users, new InvoicePaid($invoice));

// the optional 3rd argument to Notification::send()/sendNow() restricts the
// dispatch to a channel set; a literal filter is captured as `channels` on
// the dispatch site:
Notification::send($users, new InvoicePaid($invoice), ['mail', SlackChannel::class]);

A literal channel-filter argument on Notification::send() / Notification::sendNow() — an array of string channel names and/or Class::class channel constants — is recorded as an optional channels array on the notified_from dispatch site, using the same value shape as via(). It's captured only on the facade form (the ->notify(...) method form has no channel-filter argument) and omitted when the argument is absent, empty, or non-literal.

Dispatches — every handler body, cross-linked back to the listener, observer, or job it runs in

class SendOrderConfirmation
{
    public function handle(OrderPlaced $event): void
    {
        // attributed to this listener as listeners[].dispatches
        event(new OrderConfirmationSent($event->order));
    }
}

Dynamic calls Loom can't resolve statically (event($var), container lookups) land in unresolved_dispatches[] with a reason and a file:line rather than being dropped silently. Per-scanner behavior and limitations live in docs/scanners/.

Sample output

Click to expand a representative scan against a small Laravel 13 app

{
  "loom_version": "0.2.0",
  "scanned_at": "2026-05-16T19:25:54Z",
  "laravel_version": "13.7",
  "stats": {
    "events": 1,
    "listeners": 1,
    "observers": 1,
    "jobs": 1,
    "scheduled": 1,
    "routes": 2,
    "mailables": 1,
    "notifications": 1,
    "unresolved_dispatches": 1,
    "closure_listeners": 1
  },
  "events": [
    {
      "id": "App\\Events\\OrderPlaced",
      "fqcn": "App\\Events\\OrderPlaced",
      "kind": "class",
      "file": "app/Events/OrderPlaced.php",
      "line": 11,
      "dispatched_from": [
        { "file": "app/Services/Checkout.php", "line": 87, "method": "App\\Services\\Checkout::finalize" }
      ],
      "handled_by": [
        { "listener": "App\\Listeners\\SendOrderConfirmation", "method": "handle" }
      ]
    }
  ],
  "model_events": [
    {
      "id": "eloquent.creating: App\\Models\\User",
      "kind": "model_event",
      "model": "App\\Models\\User",
      "event": "creating",
      "handled_by": ["App\\Observers\\UserObserver::creating"]
    }
  ],
  "listeners": [
    {
      "fqcn": "App\\Listeners\\SendOrderConfirmation",
      "file": "app/Listeners/SendOrderConfirmation.php",
      "line": 14,
      "handles": [
        { "event": "App\\Events\\OrderPlaced", "method": "handle" }
      ],
      "registration": "auto_discovered",
      "queued": true,
      "dispatches": [
        {
          "target": "App\\Events\\OrderConfirmationSent",
          "kind": "event",
          "confidence": "high",
          "file": "app/Listeners/SendOrderConfirmation.php",
          "line": 31
        }
      ]
    }
  ],
  "observers": [
    {
      "fqcn": "App\\Observers\\UserObserver",
      "file": "app/Observers/UserObserver.php",
      "line": 9,
      "observes": "App\\Models\\User",
      "registration": "attribute",
      "hooks": ["created", "deleted", "updated"],
      "dispatches": []
    }
  ],
  "jobs": [
    {
      "fqcn": "App\\Jobs\\ProcessOrder",
      "file": "app/Jobs/ProcessOrder.php",
      "line": 14,
      "queued": true,
      "queue_config": {
        "connection": "redis",
        "queue": "high",
        "delay": null,
        "tries": 3,
        "timeout": 60,
        "backoff": null
      },
      "dispatched_from": [
        {
          "file": "app/Services/Checkout.php",
          "line": 91,
          "method": "App\\Services\\Checkout::finalize",
          "overrides": { "connection": "redis", "queue": "high", "delay": 60 }
        }
      ],
      "dispatches": []
    }
  ],
  "scheduled": [
    {
      "kind": "command",
      "name": null,
      "target": "mail:send {--queue=default}",
      "arguments": [],
      "queue": null,
      "connection": null,
      "cron": "0 13 * * *",
      "frequency": null,
      "timezone": "America/Chicago",
      "without_overlapping": true,
      "without_overlapping_expires_at": null,
      "on_one_server": false,
      "run_in_background": false,
      "even_in_maintenance_mode": false,
      "constraints": ["weekdays"],
      "file": "app/Console/Kernel.php",
      "line": 28
    }
  ],
  "routes": [
    {
      "method": "GET",
      "uri": "orders/{order}",
      "name": "orders.show",
      "controller_fqcn": "App\\Http\\Controllers\\OrderController",
      "controller_method": "show",
      "middleware": ["web", "auth"],
      "file": "routes/web.php",
      "line": 19,
      "dispatches": [
        {
          "target": "App\\Events\\OrderShipped",
          "kind": "event",
          "confidence": "high",
          "file": "app/Http/Controllers/OrderController.php",
          "line": 42
        }
      ]
    },
    {
      "method": "POST",
      "uri": "webhooks/stripe",
      "name": null,
      "controller_fqcn": null,
      "controller_method": null,
      "middleware": [],
      "file": "routes/api.php",
      "line": 7,
      "dispatches": []
    }
  ],
  "mailables": [
    {
      "fqcn": "App\\Mail\\OrderShipped",
      "file": "app/Mail/OrderShipped.php",
      "line": 18,
      "queued": true,
      "queue_config": {
        "connection": null,
        "queue": "mail",
        "delay": null,
        "tries": 3,
        "timeout": null,
        "backoff": null
      },
      "sent_from": [
        {
          "file": "app/Services/Checkout.php",
          "line": 94,
          "method": "App\\Services\\Checkout::finalize",
          "overrides": { "locale": "fr", "mailer": "ses" }
        }
      ]
    }
  ],
  "notifications": [
    {
      "fqcn": "App\\Notifications\\InvoicePaid",
      "file": "app/Notifications/InvoicePaid.php",
      "line": 22,
      "queued": true,
      "queue_config": {
        "connection": null,
        "queue": "notifications",
        "delay": null,
        "tries": null,
        "timeout": null,
        "backoff": null
      },
      "channels": ["mail", "database", "slack"],
      "channels_dynamic": false,
      "notified_from": [
        {
          "file": "app/Services/Billing.php",
          "line": 51,
          "method": "App\\Services\\Billing::charge",
          "overrides": { "queue": "emails" }
        },
        {
          "file": "app/Services/Billing.php",
          "line": 88,
          "method": "App\\Services\\Billing::charge",
          "channels": ["mail", "App\\Channels\\SlackChannel"]
        }
      ]
    }
  ],
  "unresolved_dispatches": [
    {
      "file": "app/Services/Notifier.php",
      "line": 42,
      "expression": "event($eventClass)",
      "reason": "dynamic_class_name"
    }
  ],
  "closure_listeners": [
    {
      "event": "App\\Events\\OrderPlaced",
      "file": "app/Providers/EventServiceProvider.php",
      "line": 38,
      "end_line": 40,
      "registration": "event_listen_call",
      "queued": false,
      "dispatches": [
        {
          "target": "App\\Events\\OrderConfirmationSent",
          "kind": "event",
          "confidence": "high",
          "file": "app/Providers/EventServiceProvider.php",
          "line": 39
        }
      ]
    }
  ]
}

The JSON shape is defined by schema/loom-index.schema.json and validated on every scan.

Consuming the index (PHP API)

loom:show is for humans; for programs, load a written index into typed objects with IndexLoader. The getters and lookups on Index return read-model value objects from Lucasp\Loom\Index\Model\ — no raw-array digging.

use Lucasp\Loom\Index\IndexLoader;

$index = (new IndexLoader())->fromFile('storage/loom/index.json');

foreach ($index->events() as $event) {
    echo $event->fqcn, "\n";
}

foreach ($index->handlersOf('App\\Events\\OrderShipped') as $handler) {
    echo "  handled by {$handler->listener}::{$handler->method}\n";
}

This is the supported surface for tools that consume an index. See docs/index-api.md for the full loader, getters, lookups, and value-object reference.

GitHub Action

A composite action gates pull requests on Loom: it scans the branch, checks the index against policy, diffs it against the base ref, and posts a sticky PR comment.

- uses: actions/checkout@v4
- uses: lucasp1337/laravel-loom@v1
  with:
    strict: "true"

The action runs inside your Laravel app (the repo that has laravel-loom installed). Inputs, outputs, and the baseline trade-off are in docs/github-action.md.

MCP server

loom:mcp starts a local, read-only MCP server over the index, so an AI agent can query your event graph instead of grepping source. It runs embedded — laravel/mcp auto-discovers it, nothing to wire up.

php artisan loom:mcp   # serves storage/loom/index.json over stdio

It exposes eleven tools — lookups (list-entities, get-entity), edges (handlers-for, dispatch-sites-for, dispatches-from), chains (events-following, route-to-events), and analysis (impact-of-change, find-orphans). Point any stdio MCP client at php artisan loom:mcp with your project as the working directory. The full tool reference and client config are in docs/mcp.md.

Requirements

PHP 8.3+
Laravel 11, 12, or 13

Local development

Running the package needs only PHP 8.3+, but the test suite needs ext-mbstring, ext-xml, ext-dom, and ext-xmlwriter. A Dockerfile and Justfile are provided so you can run the full toolchain without those extensions on your host:

just build    # build the Docker dev image (once)
just install  # composer install
just check    # PHPStan + Pint --test + Pest
just coverage # Pest with per-file coverage

See docs/contributing.md for the full list of recipes.

A benchmark suite (composer bench) measures scan cost across generated tiny/medium/large apps and gates CI on deterministic counts — see benchmarks/README.md.

Documentation

Architecture — pipeline, scanner contract, cross-link pass
Schema — JSON schema reference
Index PHP API — load an index into typed objects (IndexLoader, getters, value objects)
GitHub Action — the composite action that gates PRs on Loom
MCP server — the embedded loom:mcp server and its eleven tools for AI agents
Scanners — per-scanner behavior, edge cases, known limitations
Contributing — toolchain, Docker workflow, how to add a scanner

License

The MIT License (MIT). See LICENSE.md.
