README

Drop-in schema-based form field renderer and validator. Define your fields once, render forms and validate data.

What This Package Does

This is a focused utility package that provides two core functions:

Render form fields from a schema definition
Validate submitted data against the same schema

This is not a complete form solution. You handle form submission, data persistence, and integration. This package simply generates field HTML and validates data based on your schema.

Installation

composer require codesoup/metabox-schema

Basic Usage

1. Define Your Schema

$schema = [
    'username' => [
        'type' => 'text',
        'label' => 'Username',
        'attributes' => [
            'placeholder' => 'Enter username',
            'maxlength' => 50
        ],
        'validation' => [
            'required' => true,
            'min' => 3,
            'max' => 50
        ],
        'value' => 'john_doe',
        'default' => 'guest'
    ],
    'email' => [
        'type' => 'email',
        'label' => 'Email Address',
        'validation' => [
            'required' => true,
            'format' => 'email'
        ],
        'value' => 'john@example.com'
    ]
];

2. Render Fields

use CodeSoup\MetaboxSchema\Renderer;

Renderer::render([
    'schema' => $schema,
    'entity' => null,
    'form_prefix' => 'my_form'
]);

This outputs HTML form fields. You wrap them in your own <form> tags and handle submission.

3. Validate Submitted Data

use CodeSoup\MetaboxSchema\Validator;

$validator = new Validator();
$validated_data = $validator->validate( $_POST['my_form'], $schema );

if ( $validator->hasErrors() ) {
    $errors = $validator->getErrors();
    // Display errors to user
} else {
    // Save validated data to database
}

Schema Reference

Field Configuration

Each field in your schema supports these properties:

Property	Type	Description
`type`	string	Field type: text, email, url, number, date, password, tel, color, range, textarea, select, heading
`label`	string	Field label text
`value`	mixed/callable/string	Current field value, callable, or entity method name
`default`	mixed/callable	Default value or callback function (used when value is empty)
`attributes`	array	HTML attributes (placeholder, maxlength, class, etc.)
`validation`	array	Validation rules (see below)
`sanitize`	callable/array	Sanitization callback(s)
`help`	string	Help text displayed below field
`wrapper`	string	Wrapper element: 'p' (default), 'div', 'span', '' (no wrapper)
`options`	array	Options for select fields (key => label)
`rows`	int	Number of rows for textarea (default: 5)
`grid`	string	Grid layout: 'start' or 'end'
`heading_tag`	string	Heading tag for heading type: h1-h6 (default: h6)

Field Values

The value property determines what value is displayed in the field. It supports four approaches:

1. Static Value

'username' => [
    'type' => 'text',
    'label' => 'Username',
    'value' => 'john_doe'
]

2. Entity Method Name (with entity)

When an entity object is provided, value can be a method name that will be called on the entity:

'username' => [
    'type' => 'text',
    'label' => 'Username',
    'value' => 'getUsername'
]

// Renderer::render([
//     'schema' => $schema,
//     'entity' => $userObject,
//     'form_prefix' => 'my_form'
// ]);

3. Callable (deferred execution)

Pass a function name or callable - it will be executed when the field is rendered:

'username' => [
    'type' => 'text',
    'label' => 'Username',
    'value' => 'get_current_user_name'
]

4. Immediate Execution

Execute the function when defining the schema:

'username' => [
    'type' => 'text',
    'label' => 'Username',
    'value' => get_current_user_name()
]

Priority: value takes precedence over default. If value is not set, default is used.

How Value Resolution Works

The Field class resolves values in this order:

Check if value is callable - If is_callable($value) returns true, the callable is executed
Check if value is entity method - If value is a string, entity exists, and entity has that method, call it
Return static value - Otherwise, return the value as-is

Important Distinctions:

// Callable reference (deferred) - Field class calls it during render
'value' => 'get_current_user_name'

// Immediate execution - Executes NOW when schema is defined
'value' => get_current_user_name()

// Entity method (deferred) - Field class calls it during render
'value' => 'getUsername'  // requires entity object

// Static value - Used as-is
'value' => 'john_doe'

When to use each approach:

Callable reference: When you want the value fetched at render time (e.g., current timestamp, session data)
Immediate execution: When you want the value captured at schema definition time
Entity method: When working with objects (WordPress posts, database models, etc.)
Static value: When you have a fixed value or pre-fetched data

Complete Example

// Without entity - use static values
$schema = [
    'username' => [
        'type' => 'text',
        'label' => 'Username',
        'value' => 'john_doe'
    ]
];

Renderer::render([
    'schema' => $schema,
    'entity' => null,
    'form_prefix' => 'my_form'
]);

// With entity - use method names
class User {
    public function getUsername(): string {
        return 'john_doe';
    }
}

$schema = [
    'username' => [
        'type' => 'text',
        'label' => 'Username',
        'value' => 'getUsername'
    ]
];

Renderer::render([
    'schema' => $schema,
    'entity' => new User(),
    'form_prefix' => 'my_form'
]);

// Callable examples
$schema = [
    'timestamp' => [
        'type' => 'text',
        'label' => 'Current Time',
        'value' => 'time'  // Deferred: calls time() when field renders
    ],
    'captured_time' => [
        'type' => 'text',
        'label' => 'Captured Time',
        'value' => time()  // Immediate: captures time() NOW
    ]
];

Validation Rules

Available validation rules in the validation array:

Rule	Type	Description
`required`	bool	Field is required
`min`	int	Minimum length (text) or value (number)
`max`	int	Maximum length (text) or value (number)
`pattern`	string	Regular expression pattern
`format`	string	Format validation: 'email', 'url', 'date'
`validate`	callable	Custom validation callback

Custom Error Messages

Override default error messages in the errors array:

'username' => [
    'validation' => [
        'required' => true,
        'min' => 3
    ],
    'errors' => [
        'required' => 'Please enter a username',
        'min' => 'Username is too short'
    ]
]

Sanitization

Specify sanitization with a callback or array of callbacks:

'username' => [
    'sanitize' => 'sanitize_text_field'
]

'bio' => [
    'sanitize' => ['trim', 'strip_tags', 'sanitize_textarea_field']
]

Default sanitization by type:

number - Converts to float, supports decimals and negatives
email - Email sanitization
url - URL sanitization
textarea - Textarea sanitization
Others - Text field sanitization

Extending Classes

All core classes (Validator, Field, Renderer) are designed to be extensible. All internal methods are protected, allowing you to extend and customize behavior.

Extend Validator

Add custom validation rules and sanitization:

use CodeSoup\MetaboxSchema\Validator;

class CustomValidator extends Validator {
    protected function sanitizeByType($value, string $type): mixed {
        return match($type) {
            'phone' => $this->sanitizePhone($value),
            'slug' => $this->sanitizeSlug($value),
            default => parent::sanitizeByType($value, $type),
        };
    }

    protected function validateValue($value, array $context): string|bool {
        // Add custom validation logic
        if ($context['type'] === 'phone') {
            return $this->validatePhone($value, $context);
        }
        return parent::validateValue($value, $context);
    }

    private function sanitizePhone($value): string {
        return preg_replace('/[^0-9+\-() ]/', '', (string) $value);
    }
}

$validator = new CustomValidator();

Extend Renderer

Customize rendering behavior:

use CodeSoup\MetaboxSchema\Renderer;

class BootstrapRenderer extends Renderer {
    protected function openGrid(): void {
        printf('<div class="row">');
    }

    protected function renderField(...$args): void {
        printf('<div class="col-md-6">');
        parent::renderField(...$args);
        printf('</div>');
    }
}

BootstrapRenderer::render(['schema' => $schema, ...]);

Extend Field

Customize field rendering:

use CodeSoup\MetaboxSchema\Field;

class CustomField extends Field {
    protected function generateFieldId(): string {
        return 'custom-' . parent::generateFieldId();
    }

    public function getAttributesString(): string {
        // Add custom data attributes
        $attrs = $this->getAttributes();
        $attrs['data-field-name'] = $this->config['name'];
        // ... custom logic
    }
}

Custom Templates

You can override field templates to customize HTML output.

Override All Templates

Use template_base to specify a custom template directory:

Renderer::render([
    'schema' => $schema,
    'entity' => null,
    'form_prefix' => 'my_form',
    'template_base' => __DIR__ . '/templates'
]);

Create these files in your templates directory:

input.php - For all input types
textarea.php - For textarea fields
select.php - For select dropdowns
label.php - For field labels
help.php - For help text
heading.php - For heading elements

Override Single Field Template

Use template_path in a specific field to override just that field:

'featured_content' => [
    'type' => 'textarea',
    'label' => 'Featured Content',
    'template_path' => __DIR__ . '/templates/featured-textarea.php'
]

Available Methods in Templates

Inside template files, $this refers to the Field object:

$this->getFieldId()          // Field ID attribute
$this->getFieldName()        // Field name attribute
$this->getLabel()            // Field label
$this->getValue()            // Field value
$this->getType()             // Field type
$this->isRequired()          // Is field required?
$this->getRequiredAttr()     // Required attribute string
$this->getAttributesString() // Custom attributes string
$this->getHelp()             // Help text
$this->getRows()             // Textarea rows
$this->getOptions()          // Select options
$this->getHeadingTag()       // Heading tag (h1-h6)

What You Need to Provide

This package does not include:

Form tags (<form> wrapper)
Submit buttons
CSRF/nonce handling
Form submission handling
Data persistence
Success/error message display
CSS styling (except basic structure)

You integrate this into your existing form handling workflow.

WordPress Integration

Works with WordPress functions when available, falls back to PHP alternatives otherwise. Suitable for WordPress metaboxes, settings pages, or standalone forms.

WordPress Integration Example

Here is how to use this package with WordPress metaboxes using a class-based approach:

1. Define your schema (wp/schema.php):

return [
    'product_price' => [
        'type' => 'number',
        'label' => 'Product Price',
        'validation' => ['required' => true, 'min' => 0],
        'value' => 'getProductPrice'
    ],
    'product_sku' => [
        'type' => 'text',
        'label' => 'SKU',
        'validation' => ['required' => true],
        'value' => 'getProductSku'
    ]
];

2. Create metabox class:

use CodeSoup\MetaboxSchema\Renderer;
use CodeSoup\MetaboxSchema\Validator;

class ProductDetailsMetabox {

    private array $schema;

    public function __construct() {
        $this->schema = require __DIR__ . '/wp/schema.php';
        $this->registerHooks();
    }

    private function registerHooks(): void {
        add_action( 'add_meta_boxes', [ $this, 'registerMetabox' ] );
        add_action( 'save_post_product', [ $this, 'saveMetabox' ] );
        add_action( 'admin_notices', [ $this, 'displayErrors' ] );
    }

    public function registerMetabox(): void {
        add_meta_box(
            'product_details',
            'Product Details',
            [ $this, 'renderMetabox' ],
            'product',
            'normal',
            'high'
        );
    }

    public function renderMetabox( $post ): void {
        wp_nonce_field( 'product_details_nonce', 'product_details_nonce' );

        // Create entity wrapper for post meta
        $entity = new class($post) {
            public function __construct(private $post) {}

            public function getProductPrice() {
                return get_post_meta($this->post->ID, 'product_price', true);
            }

            public function getProductSku() {
                return get_post_meta($this->post->ID, 'product_sku', true);
            }
        };

        Renderer::render([
            'schema' => $this->schema,
            'entity' => $entity,
            'form_prefix' => 'product_meta'
        ]);
    }

    public function saveMetabox( int $post_id ): void {
        // Verify nonce and permissions
        if ( ! $this->shouldSave( $post_id ) ) {
            return;
        }

        // Validate data
        $validator = new Validator();
        $validated_data = $validator->validate( $_POST['product_meta'], $this->schema );

        if ( $validator->hasErrors() ) {
            set_transient( 'product_meta_errors_' . $post_id, $validator->getErrors(), 45 );
            return;
        }

        // Save validated data
        foreach ( $validated_data as $key => $value ) {
            update_post_meta( $post_id, $key, $value );
        }
    }

    public function displayErrors(): void {
        global $post;

        $errors = get_transient( 'product_meta_errors_' . $post->ID );

        if ( $errors ) {
            // Display error notice
        }
    }
}

new ProductDetailsMetabox();

See examples/wordpress-metabox.php and examples/wp/schema.php for the complete implementation.

Examples

See the examples/ folder for complete working examples:

examples/simple-form.php - Basic form rendering
examples/basic-usage.php - Comprehensive schema with all field types and validation
examples/wordpress-metabox.php - Complete WordPress metabox class implementation
examples/wp/schema.php - Example schema for WordPress metabox
examples/custom-templates.php - Using custom template directory for all fields
examples/override-single-field.php - Override template for a specific field
examples/templates/ - Custom template files (Bootstrap-style examples)
examples/extend-validator.php - Extending Validator class with custom validation rules
examples/extend-renderer.php - Extending Renderer and Field classes with Bootstrap integration

Requirements

PHP 8.1 or higher

Contributing

Issues and pull requests are welcome on GitHub.

To report a bug or request a feature, please open an issue.

License

MIT

codesoup / metabox-schema

Maintainers

Details
