codesoup/metabox-schema

Schema-driven form builder system for WordPress. Define fields as PHP arrays, use Renderer class to render forms and sanitize POST data. Use Validator to validate user input against your schema.

dev-master 2026-03-15 08:34 UTC

Requires

• php: >=8.1

Requires (Dev)

• dealerdirect/phpcodesniffer-composer-installer: ^1.0
• php-parallel-lint/php-console-highlighter: ^1.0
• php-parallel-lint/php-parallel-lint: ^1.3.1
• phpcompatibility/phpcompatibility-wp: ^2.1
• wp-coding-standards/wpcs: ^3.0

MIT

• Code Soup

• form
• schema
• wordpress
• validation
• renderer
• metabox

README

Schema-driven form builder system for WordPress. Define fields as PHP arrays, use Renderer class to render forms and sanitize POST data. Use Validator to validate user input against your schema.

What This Package Does

1. Render form fields from a schema definition
2. Sanitize and validate submitted data against the same schema

Key Features

• 15+ field types included
• Custom field type registration support
• Template override (global, per-type, per-field)
• Extensible validation and rendering
• WordPress media library integration
• Grid layout support
• PHP 8.0+ with strict typing
• Agent skills for AI-assisted development, compatible with Skillshare.

Installation

composer require codesoup/metabox-schema

Quick Start

use CodeSoup\MetaboxSchema\Renderer;
use CodeSoup\MetaboxSchema\Validator;

// 1. Define schema
$schema = [
    'email' => [
        'type' => 'email',
        'label' => 'Email',
        'validation' => [ 'required' => true ]
    ]
];

// 2. Render fields
Renderer::render([
    'schema' => $schema,
    'form_prefix' => 'contact'
]);

// 3. Validate data
$validator = new Validator();
$validated_data = $validator->validate( $_POST['contact'], $schema );

if ( $validator->has_errors() ) {
    $errors = $validator->get_errors();
}

Examples

See the docs/ directory for complete working examples:

• basic-usage.php - Complete form rendering and validation
• custom-templates.php - Override default field templates
• extend-validator.php - Add custom validation rules
• extend-renderer.php - Customize rendering behavior

Core Concepts

Schema

Array defining field structure, validation rules, and configuration:

$schema = [
    'field_name' => [
        'type' => 'text',
        'label' => 'Field Label',
        'value' => 'default',
        'validation' => [
            'required' => true,
            'min' => 3,
            'max' => 50,
            'pattern' => '^[a-zA-Z0-9]+$'
        ],
        'errors' => [
            'required' => 'Please enter a value',
            'min' => 'Value is too short'
        ],
        'attributes' => [
            'class' => 'custom-class another-class',
            'placeholder' => 'Enter value',
            'maxlength' => 50,
            'data-custom' => 'value',
            'data-validate' => 'true'
        ],
        'help' => 'Help text'
    ]
];

Supported Field Types

Input Fields:

• text, email, url, number, date, password, tel, color, range

Content Fields:

• textarea - Multi-line text input
• select - Dropdown with options
• wp_editor - WordPress rich text editor
• media - WordPress media library picker

Display Fields:

• html - HTML content display
• label - Field labels
• help - Help text

Validation Rules

• required - Field must have value
• min / max - Min/max value or length
• format - Format validation (email, url, date)
• pattern - Regex pattern

Custom error messages via 'errors' array (see schema example above).

Field IDs and Attributes

Each field automatically gets an ID in format form-prefix-field-name. Use attributes array for CSS classes and data attributes. Note: id and name in attributes are ignored (auto-generated).

Value Resolution

Fields can get values from:

1. Static 'value' in schema
2. Callable 'value' => fn() => get_option('key')
3. Entity methods 'value' => 'get_email' (calls $entity->get_email())
4. Values array passed to Renderer

Custom Templates

Templates are organized in subdirectories by field type:

templates/
├── input/
│   └── template.php
├── textarea/
│   └── template.php
├── select/
│   └── template.php
└── ...

Override templates globally or per-field:

// Global override
Renderer::render([
    'schema' => $schema,
    'template_base' => __DIR__ . '/templates'
]);

// Single field override
$schema['bio']['template_path'] = __DIR__ . '/templates/textarea/custom.php';

See docs/custom-templates.php and docs/templates/ for details.

API Reference

Renderer

Renderer::render([
    'schema' => $schema,        // Required
    'form_prefix' => 'my_form', // Required
    'entity' => $object,        // Optional
    'values' => $array,         // Optional
    'template_base' => $path    // Optional
]);

Validator

$validator = new Validator();
$validated_data = $validator->validate( $data, $schema );

if ( $validator->has_errors() ) {
    $errors = $validator->get_errors();
    // Returns: [ 'email' => 'Email is required', 'age' => 'Age must be at least 18' ]
}

Field Methods (Available in Templates)

Common Methods (All Fields):

• get_field_id(), get_field_name(), get_type(), get_label()
• get_value(), get_escaped_value(), get_escaped_textarea_value()
• is_required(), get_required_attr(), get_attributes_string()
• get_help(), get_wrapper()

Field-Specific Methods:

• get_rows() - Textarea, WP_Editor
• get_options() - Select
• get_editor_settings() - WP_Editor
• get_content() - HTML
• get_button_text(), get_media_type(), get_preview_size() - Media

See docs/templates/ for template usage examples.

Extending

Custom Validator

class Custom_Validator extends Validator {
    protected function validate_value( $value, $context ) {
        // Custom validation logic
        return parent::validate_value( $value, $context );
    }
}

See docs/extend-validator.php for complete example.

Custom Renderer

class Custom_Renderer extends Renderer {
    protected function render_field( $field_name, $field_config ) {
        // Custom rendering logic
        parent::render_field( $field_name, $field_config );
    }
}

See docs/extend-renderer.php for complete example.

Architecture

• Renderer - Static render() method, extensible protected methods
• Validator - Instance-based, extensible validation rules
• Field_Factory - Creates field instances from configuration
• Abstract_Field - Base class for all field types
• Field Classes - Input_Field, Textarea_Field, Select_Field, Media_Field, WP_Editor_Field, HTML_Field, Label_Field, Help_Field
• Value_Resolver - Trait for resolving values from multiple sources
• String_Formatter - Utility for string transformations
• Config_Sanitizer - Sanitizes and validates configuration arrays
• Constants - Default values and configuration constants

Requirements

• PHP 8.1+
• WordPress 5.0+ (for escaping functions, wp_editor, and media library)

Agent Skills

This package includes Agent Skills for AI-assisted development, compatible with Skillshare.

Available Skills

• schema-definition - Define field schemas with validation rules
• field-renderer - Render forms from schemas
• template-creator - Create custom field templates
• validator - Validate and sanitize user input
• custom-field-registration - Register custom field types
• utilities - Use utility classes

Installation

# Local installation (recommended)
cd /path/to/metabox-schema
skillshare install ./skills --track
skillshare sync

From GitHub

# SSH
skillshare install [e-mail]:code-soup/metabox-schema.git/skills

# HTTPS with token
export GITHUB_TOKEN=your_token_here
skillshare install github.com/code-soup/metabox-schema/skills

See skills/README.md for details.

License

MIT License - See LICENSE file for details.
